Afd600 Aluminum Flexible Duct Forming Machine for Ventilation
Nantong Zhenhuan Trade Co., Ltd.- After-sales Service：Engineers Available to Service Outside
- Warranty：1 Year
- Control Type：PLC Control
- Inverter：Mitsubishi From Japan
- Diameter Range：80-800mm
- Raw Material：Aluminum, Wire, Glue
Base Info
- Model NO.：AFD600
- Length of Aluminum Tube：1-10m
- Working Speed：1-35m,Min
- Main Motor Power：1.5kw
- Heating Power：2.4kw
- Weight：750kg
- Brand：Zhenhuan
- Transport Package：Wooden Case
- Trademark：Zhenhuan
- Origin：Jiangsu, China
- HS Code：84552290
- Production Capacity：100 Sets Per Year
Description
Basic Info.
Model NO. AFD600 Length of Aluminum Tube 1-10m Working Speed 1-35m/Min Main Motor Power 1.5kw Heating Power 2.4kw Weight 750kg Brand Zhenhuan Transport Package Wooden Case Trademark Zhenhuan Origin Jiangsu, China HS Code 84552290 Production Capacity 100 Sets Per YearProduct Description
Aluminum Flexible Duct Forming Machine
This aluminum flexible duct forming machine is specially for producing aluminum flexible ducts with aluminum foil or metalized PET film with steel wire reinforced for ventilation purpose.
Main technical data for aluminum flexible duct forming machine
| No. | Item | Data |
| 1 | Diameter range | 60-600mm |
| 2 | Length of aluminum tube | 1-10m |
| 3 | Raw material | metalized PET film, 0.023mm, width 40-60mm, Steel wire 0.8-1.4mm dia. |
| 4 | Dimension | 2200 x 820 x 1550mm |
| 5 | Weight | About 750kg |
| 6 | Main motor power | 1.5kW |
| 7 | Temperature | 40~120º |
| 8 | Electric heating power | 2.4kW |
| 9 | Working speed | 1~35m/min |
| 10 | Feature of finished ducts | Temperature resistance: -30°C-140°C Max. air flux: 30m/s Max. working pressure: 2500Pa Pitch between corrugations: 20mm |
Finished product by aluminum flexible duct forming machine
