• Model NO.：J212, J213, J314, J215, J219, J2110, J2113, J2118
• Suitable for：Zinc, Zamak, Pb Alloy
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Warranty：12 Months
• PLC：Mitsubishi
• Motor Voltage：380V, 220V, 415V etc.
• Production Experience：Since1987
• Transport Package：Full Container Load
• Specification：SGS
• Trademark：YINSHAN
• Origin：Ningbo, China
• HS Code：8454309000
• Production Capacity：600sets,Year

Basic Info.

Model NO. J212, J213, J314, J215, J219, J2110, J2113, J2118 Suitable for Zinc, Zamak, Pb Alloy After-Sales Service Provided Engineers Available to Service Machinery Overseas Warranty 12 Months PLC Mitsubishi Motor Voltage 380V, 220V, 415V etc. Production Experience Since1987 Transport Package Full Container Load Specification SGS Trademark YINSHAN Origin Ningbo, China HS Code 8454309000 Production Capacity 600sets/Year

Product Description

Introduction:

The hot chamber die casting machines are applicable to die casting of non-ferrous metals with low melting point such as zinc and Pb.

It is widely used in various industries including automobile and motorcycle parts, meters and instruments, daily-use hardware, and household appliances.
There are 16ton, 25ton/30ton, 380ton, 50ton, 58ton, 68ton, 66ton, 88ton/90ton, 110ton, 130ton, 190ton hot chamber die casting machines.



Technical Data Sheet:


The project	Unit	J2118	J2113	J2110	J219A	J216E	J215A	J214	J213E	J213B	J213D	J212
Die locking force	kN	1900	1300	1100	900	680	580	500	380	300	300	160
Stroke of moving platen	mm	350	350	270	270	240	210	210	210	200	200	125
Inner space between the bars (H×V)	mm	480×450	430×430	360×360	360×360	300×300	311×311	290×290	270×270	240×240	240×240	230×200
Thickness of die block (min/max)	mm	200/550	250/500	200/450	120/360	150/350	120/320	120/320	120/320	120/320	120/320	150/220
Injection force	kN	100	100	83	75	66	60	50	45	30	30	19
Injection stroke	mm	160	148	160	130	130	130	110	110	110	110	80
Injection position	mm	0,-80	0,-80	0,-60	0,-60	0,-60	0,-50	0,-40	0,-45	0,-40	0,-40
Ejection force	kN	100	90	85	60	55	50	50	45	35	35
Ejection stroke	mm	80	85	70	60	60	60	50	50	50	50
Diameter of shot sleeve	mm	65 70	60	60	60	50	50	50	50	45	45	38
Max. projecting area of casting	cm2	617	395	340	236	202	189	159	134	132	132	80
Working pressure of vane pump	MPa	12	12	13.5	12	11.5	11.5	10.5	9	7	7	6.3
Motor power	kW	11	11	11	11	11	9.5	9.5	7.5	7.5	7.5	5.5
Dosage of fluid metal per shot (zinc)	kg	2.5(3.5)	2.5	2.5	1.6	1.5	1.3	1.1	1.1	0.6	0.6	0.21
Effective volume of crucible (zinc)	kg	450	350	350	350	280	200	160	160	160	160	160
Oil consumption of burner	kg/h	1.5-9	1.5-7	1.5-7	1.5-6	1.5-6	1.5-6	1.5-6	1.5-6	1.5-6	1.5-6	1.5-6
Volume of oil tank	L	500	450	445	250	335	310	320	320	250	250	220
Machine weight	kg	5800	5500	5500	4700	4000	3500	3500	3300	2900	2800	2200
Overall dimensions (L×W×H)	mm	4550×1660×2280	5200×1600×2300	3940×1630×2563	4300×1800×2250	3732×1602×2563	3600×1500×2000	3500×1450×2100	3500×1450×2100	2900×1320×1880	3407×1273×2542	2790×1200×1935
