• Model NO.：XE1100HB3-120
• Cutting Length：460~1200mm
• Cutting Frequency：120cuts,Min
• Linear Velocity：10-100m,Min
• Item No.：Xe1100hb3-120
• Transport Package：File
• Specification：SGS
• Trademark：xuanen
• Origin：Zhejiang Hangzhou
• Production Capacity：50 Set,Year

Basic Info.

Model NO. XE1100HB3-120 Cutting Length 460~1200mm Cutting Frequency 120cuts/Min Linear Velocity 10-100m/Min Item No. Xe1100hb3-120 Transport Package File Specification SGS Trademark xuanen Origin Zhejiang Hangzhou Production Capacity 50 Set/Year

Product Description

Middle Speed Scroll Cutting Line to Length



BRIEF INTRODUCTION
This scroll cutting line is a special equipment to decoil, level, shear the coil material of tinplate and aluminum coils.It is an important equipment to reduce the production cost by decreasing the waste of coil material in making iron tank and cover.Adopting this scroll cutting line can help you to save coil material by 3%-8%.

It consists of decoiler, leveler, scroll cutter, belt conveyor, three material receiving platforms, pinhole detector and electric control cabinet.This line can produce different products with one machine only by changing corresponding dies with an automatic die changing system.The cutting frequency is 120times per minute.It  also provides with a pinhole detector device-Photomultiplier pinhole detector which can detect the pinhole in high accuracy.

MAIN TECHNICAL PARAMETERS
Cutting materials:Tinplate, aluminum band;
Cutting thickness :0.15~0.5mm;
Cutting width:600~1100mm;
Cutting length:460~1200mm;
Cutting frequency:120cuts/min (while cutting length reaching 750mm-800mm)
Cutting linear velocity:10-100m/min;
Stacker loaded weight:2T;
Height of stacker:460mm(including bracket);
Length tolerance:≤±0.25mm/m;
Diagonal tolerance:≤±0.15mm;
Decoiling expansion range:Φ380~φ450mm orφ450~φ520mm;
Maximum OD of coil material:Φ1800mm;
Maximum weight of coil material:10T;
Occupation Area:21.7×5.6M
Feature
1)
High speed decoiler with cantilever support, adopting ground recoiling, reduces the heavy labor of excavating a pit
2)
Its control system has three options, Schneider , Mitsubishi or Siemens, the customers can choose  either  based on demands.
3)
High accuracy of gauge, good shearing quality, and high production efficiency
4)
Do not need store material foundation pit, lowering the foundation processing cost
5)
Belt conveyor has flap institution;It is much easier for user to change mold.
6)
The quantity of material receiving platform can be custom made.
7)
Sheet piling could choose servo electromagnetic stacking institution according to practical demands
