Slot Die Coatingbuilding Material
Hangzhou Zhongneng Photoelectricity Technology Co., Ltd.- Warranty：1 Year
- Coating：Coil Coating
- Substrate：Steel
- Certification：ISO
- Condition：New
- Coating Head Liquid Tank：0.5-5 Ml
Base Info
- Model NO.：SDC18V2
- Coating Head Precision：+-2um,M
- Coating Width：50, 100, 150, 200mm
- Coating Speed：0.1-10mm,S
- Coating Thickness：50-3000nm
- Equipment Power：500W(Without Heating)
- Weight：150kg
- Transport Package：Wooden Box Shockproof
- Specification：850*300*850
- Trademark：PEROVS
- Origin：Hangzhou
- Production Capacity：60 Sets,Year
Description
Functional parameters:
1.High precision vertical axis positioning system.
2. Custom designed low reservoir coating head, saving a lot of solvent waste.
3. High precision vacuum adsorption platform for more uniform coating.
4. Multifunctional pump body, can be installed with multiple types and capacities of syringes.
5. Fully automatic cleaning function.
6. Fine-adjustable platform and coating head, significantly reduce the requirements of the substrate itself.
