Roof Tile Rolling Machine Metal Step Tile Forming Machine
Hangzhou Zhongyuan Machinery Factory- After-sales Service：Provide
- Warranty：1 Year
- Coil Thickness：0.4-0.5mm
- Diameter of Shaft for Rollers：72mm
- Main Power：5.5kw
- Voltage：380V,3phase,50Hz(or Depend on Customer)
Base Info
- Model NO.：tile forming machine
- Control System：Mitsubishi PLC and Transducer (Japan)
- Coil Width：1200mm
- Suitable Raw Materials：Aluminum Coils
- Yield Strength of Raw Material：235MPa or 34ksi
- Working Speed：About 5-6m,Min. (Including The Cutting& Pressing
- Hydraulic Station Power：7.5kw
- Transport Package：40gp
- Specification：CE SGS BV
- Trademark：Zhongyuan
- Origin：Hangzhou
- HS Code：84552210
- Production Capacity：10sets,Month
Description
Overview
Specification Material Type Forming speed(m/min) Speed adjusting mode AC Frequency Transmission way Cutting mode Hydraulic cutting Cutter material Length measurement Encoder Control mode Operating mode Button + Mitsubishi Touch screen Main motor power(kw) 5.5KW (Depend on final design) Hydraulic station power 7.5K W (Depend on final design) Total power(kw) 13KW Uncoiler's loading capacity Max. Capacity: 5000kgs Machine`s size Machine weight 10135kgs
Components of machine:Decoiler 1set Feeding & guiding device 1set Main roll forming machine 1set Pressing device 1set Hydraulic cutting system 1set Controlling system 1set Run out table 1set
Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Pressing--Hydraulic Cutting - Product to Run Out Table
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.
Provide profile drawing & design technical support FOR FREE!
Website:cnzhongyuan.en.made-in-china.com
Factory Address:No. 228 Yongli, Nanyang Street, Xiaoshan District, Hangzhou, Zhejiang, China
Our Advantages
Product Parameters
About Roof Tile Roll Forming MachineItem
Gear-box transmission (optional)
Components of machine:
Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Pressing--Hydraulic Cutting - Product to Run Out Table
Packaging & Shipping
1. One 40feet container for loading one set machine with mechanical decoiler.
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.
