Xuanen Tinplate Recoiler

Anhui XuanHong CNC Technology Co., Ltd.
  • Transport Package：Film
  • Specification：SGS
  • Trademark：xuanen
  • Origin：Zhejiang Hangzhou

Base Info

  • Model NO.：XE1250S
  • Production Capacity：50 Set,Year

Description

Basic Info.

Model NO. XE1250S Production Capacity 50 Set/Year

Product Description

XE1250SJ Recoiler

  Application
The machine is suitable for recoiling of galvanizing line, tinning line, coldrolled
 thin plate production line and color coating line.


     Construction
It consists of hydraulic recoiler, unloading hoist and recoiling corbel.



       Feature		1.Recoiler is equipped with servo correction system.
2.Recoiler adopt gear box deceleration system.
3.Coil width can be customized.



Technical Parameters		1. Coil thickness: 0.2~1.5mm;
2. Coil width:380~1650mm;
3.  Decoiling expansion range:φ380~450mm/φ450~520mm;
4.  Max coil diameter: Φ2000mm;
5.  Max coil weight: 15T;
6. Max height of unloading hoist: 600mm;
7.  Max linear velocity: 250m/min
