Welding Positioner
Wuxi Datang Welding & Cutting Mechanical Equipment Co., Ltd.- Transport Package：After Negotiate
- Specification：Hb Standard Welding Positioner
- Trademark：Datang
- Origin：China
Base Info
- Model NO.：HB
- HS Code：84688000
- Production Capacity：500 Sets Per Month
Description
NO.Technical Parameter Type HB1 HB3 HB6 HB12 HB30 HB50 HB100 HB150 HB200 1 Rated loading (Kg) 100 300 600 1200 3000 5000 10000 15000 20000 2 Max eccenteric Distance(mm) 50 100 200 200 250 250 3 Max distance of Gravity center (mm) 150 200 300 400 500 600 4 Working table size (mm) φ 400 φ 600 φ 1000 φ 1200 φ 1400 φ 1500 φ 1800 φ 2000 φ 2200 5 The amount of table T-beam groove 4 6 6 Tilting angle (° ) 0° -90° 0° -120° 7 Rotating speed (rpm) 0.2-2 0.15-1.5 0.1-1 0.05-0.5 0.03-0.3 8 Rotating Power(KW) 0.18 0.18 0.75 0.75 1.5 2.2 3 4 5.5 9 Tilting speed (rpm) 0.8 0.5 0.3 0.14 10 Tilting Power(kW) 0.75 1.1 2.2 3 4 5.5 7.5 11 Structure of rotating axes Direct connection of reducer Tilting support 12 Speed adjusting way Rotating speed VFD Tilting speed constant
