Big Thickness Carbon Steel CNC Flame Cutting Equipment
Shanghai Tayor Heavy Industry (Group) Co., Ltd.- Customized：Customized
- Layout：Coaxial
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Laser Plasma Flame Waterjet
Base Info
- Model NO.：CNCSG
- Cutting Torch Number：Customization
- Flame Cutting Thickness：5-60mm
- Flame Cutting Speed：50-800mm,Min
- CNC System：Sjtu-Sk, Micro Edge, Edge PRO, Kp
- Programming Software：Fastcam
- Transport Package：Wooden Case and Tray
- Specification：CE, CCC, ISO
- Trademark：TAYOR
- Origin：China
- HS Code：8456901000
- Production Capacity：1000 Sets,Year
Description
Technical SpecificationModel CNCTG1520 CNCTG1530 CNCTG2060 CNCTG2580 Effective cutting area (mm) 1500x2000 1500x3000 2000x6000 2500x8000 Machine size(mm) 2000x3000 2000x4000 2500x7000 3000x9000 Suggested cutting Thickness(mm) Plasma:1-30mm Basic components Cutting Mode Plasma Structure of working table Split-type Drive Mode Dual-side Cutting Torch Number customized Driving Motor Servo motor CNC Controller Shanghai SJTU/Micro EDGE/ Shanghai KP/Shenzhen AHC Available Plasma Power source Hypertherm/Thermadyne/Kjellberg/TAYOR LGK Nesting Software FASTCAM Dust extraction Air duct Other data Operation language Multi-langue Power voltage 3×380V±10% 50HZ / according to user's local condition Optional Water surface cutting table
