• Model NO.：WZ-CLF-3000A
• Mesh Width：600-3000mm
• Weaving Way：Servo Motor
• Control Way：PLC+Touch Screen
• Working Speed：100-120sqm,Hour
• Transport Package：Sketch Film Paper and Wooden Box
• Specification：3000mm
• Trademark：Wanzhong Machine
• Origin：China
• HS Code：8463300000
• Production Capacity：40 Sets,Month

Basic Info.

Model NO. WZ-CLF-3000A Mesh Width 600-3000mm Weaving Way Servo Motor Control Way PLC+Touch Screen Working Speed 100-120sqm/Hour Transport Package Sketch Film Paper and Wooden Box Specification 3000mm Trademark Wanzhong Machine Origin China HS Code 8463300000 Production Capacity 40 Sets/Month

Product Description

Fully Automatic Chain Link Fence Machine Main Introduction:

Chain link fence machine is specially used for manufacturing chain link fences of different sizes. The wire is fed from the pay-off and pass through the mould where the DIAMOND SIZE takes place. After passing through the mould, the diamond pattern wire is automatically thrown on the winding shaft in the switching process. Once the switching is complete,the woven is manually glided down to enable the next switch to take place.

The chain link is automatically wound to form rolls when the desired length is manufactured.

The machine is controlled by PLC (MIT)automatic controller, so only one person is needed to operate it.
Fully Automatic Chain Link Fencing Making Machine Main Parameters:

Fully Automatic Single Wire Chain Link Fencing Machine

Wire diameter : 1.3-4.5mm Mesh Aperture :30*30-100*100mm Width : 500-3000mm Roll Length:30m (adjustable) Feeding wire number : single wire Capacity:0-120m2/hour Weaving Way:Servo Motor Control Way:PLC+Touch Screen(Taiwan) Materials: galvanized wires or or pvc wires or stainless wire Voltage:380V,50Hz,three phase or Customized Including: Main machine 1set Weaving machine 1set Bending or twisted edge part 1set Rolling mesh machine1set Control cabinet 1 pcs Wire pay-off 1 pcs

Fully Automatic Chain Link Fencing Making Machine Guarantee: Two years. Within two yeas after the date when the goods reach the destination port if the parts (not including easily damaged parts ) are broken for reasons which are not human.
