Tile Roof Roll Forming Machine

Zhangjiagang City Saibo Science & Technology Co., Ltd.
  • Type：Rolling Machine
  • Forging Forming Method：Mold Forging
  • Power Source：Electric
  • Feature：High Efficiency
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：YX28-155-775
  • Customized：Customized
  • Advantage：Use Widely
  • Condition：New
  • Name：Tile Roll Forming Machine
  • Color：Blue and Yellow
  • Transport Package：No Packing
  • Specification：YX28-155-775
  • Trademark：Saibo
  • Origin：Jiangsu, China
  • HS Code：84552210
  • Production Capacity：300sets,Year

Description

Item NO
Description
Offered specification Roll Forming MachineYX28-155-775 Material Width1000mm Rolling Speed2-3m/min Rolling Thickness0.3-0.7 mm GI up to 235Mpa Control SystemPLC  (Panasonic) as list in the note Un Coiler5 ton manual de-coiler Roller StationsAbout 15 stations Roller Material45# forge steel,coated with chrome Shaft Material and DIA¢70mm, material is 45# forge steel Maim Motor Power5.5kw Hydraulic Station Power5.5kw Hydraulic Pressure12-16Mpa Material Of CuttingCr12Mov quenching 58-62ºC StructureWall panel Tolerance3m+-1.5mm Electric Source380V, 50HZ,3 phase
Also can satisfy customer's require Way Of Drive1 inch single chain Color Of The MachineYellow and blue Size of the machineL*W*H   around 8.5m*1.7m*1.6m Container Need1 x40 feet

4. Packing & Delivery
Deliver time: take goods after receive deposit 60 days
Packing: suitable of ocean transportation

5. Warranty
Warranty: 1 year warranty from date of shipment
Guarantee:
1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
-  Damage occurs due to a natural disaster
-  Malfunction occurs due to user error
-  Malfunction occurs due to modifications
-  Malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 100$ per day shall be for purchaser's account if manufacturer's engineer has to be send to purchaser's factory to maintain the machine during the guarantee period.

6. Payment Term
   30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment

ATTENTION: The profile of the panel is according to the clients!
