• Model NO.：KIU Series
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• 100kw：10-30kHz
• Induction Forging：Metal
• Transport Package：Wooden Cases
• Specification：CE ROHS ISO CCC
• Trademark：KIA
• Origin：China
• HS Code：8514400090
• Production Capacity：1000 Sets,Month

Basic Info.

Model NO. KIU Series Customized Customized Advantage Use Widely Condition New 100kw 10-30kHz Induction Forging Metal Transport Package Wooden Cases Specification CE ROHS ISO CCC Trademark KIA Origin China HS Code 8514400090 Production Capacity 1000 Sets/Month

Product Description

1. This equipment adopts the IGBT inverter circuit in parallel connection, which has high load adaptability.
2. It has such features as high power, fast heating speed, high efficiency and easy operation.
3. As compared with other heating modes, it can significantly promote the economic benefits, improve the quality of heated work pieces and save the energy and material, alleviate labor intensity and improve the productive environment.
4. It has super small size, which can save production space by 10 times.
5. It is safe and reliable, and requires no equipment of ten thousand voltage, and thus can ensure the safe operation.
6. The comprehensive full load design is available for 24-hour continuous operation.


Applications:
Drill tip heat shaping
Heat treatment
Quenching
Forging
Melting
Soldering and brazing

Model	KIU-100AB
Input power	100KW
Input voltage	3 phase 380V/50-60Hz
Input voltage range	340V-420V
Output current	400-4600A
Output oscillating frequency	10-30KHZ
Duty cycle	100%
Cooing water pressure	0.4Mpa
Cooling water flow	≥32L/min
Cable length between main device-extension	1.5-2M
Weight	Main parts:102kg Extensive:75kg
Size	Main part:750*675*1050mm Extensive:850*420*650mm
