2022 4 Station Bolt Making Machine for Bolts
HARBIN RAINBOW TECHNOLOGY CO., LTD.- After-sales Service：at Sight or on Line
- Type：Forging Operation
- Forging Forming Method：Mold Forging
- Power Source：Electric
- Feature：Automation
- Certification：CCC, ISO9001, CE
Base Info
- Model NO.：RB
- Warranty：12 Months
- Customized：Customized
- Advantage：Use Widely
- Condition：New
- Transport Package：Containers
- Specification：4 Forging stations
- Trademark：Rainbow
- Origin：China
- HS Code：8463900090
- Production Capacity：100 Sets,Year
Description
Overview
Product ParametersNo. 4 4 4 4 4 4 4 FORGING FORCE kgs 120,000 210,000 210,000 350,000 350,000 430,000 430,000 MAX. CUT-OFF DIA. mm φ15 φ18 φ18 φ23 φ23 φ26 φ30 MAX. CUT-OFF LENGTH mm 310 220 380 240 360 270 340 OUTPUT pcs/min 45 - 70 60 - 100 40 - 60 50 - 85 40 - 60 40 - 60 35 - 50 MAX. P.K.O LENGTH mm 30 30 46 46 46 40 46 DIE KICK OUT LENGTH mm 280 170 320 220 325 175 280 MAIN MOTOR kw 37 45 55 75 75 110 110 CUT-OFF QUILL mm φ 55*70L φ 60*90L φ 64*100L φ 75*120L φ 75*120L φ 80*130L φ 99*150L PUNCH SIZE mm φ 60*229L φ 75*185L φ 75*185L φ 90*215L φ 90*215L φ 120*270L φ 120*270L DIE SIZE mm φ 86*305L φ 100*190L φ 100*345L φ 125*240L φ 125*345L φ 140*250L φ 148*300L DIE PITCH mm 110 120 120 140 140 160 160 APPROX. WEIGHT kgs 38,000 43,000 60,000 62,000 75,000 105,000 131,000 DIA. OF PRODUCTION mm 8 - 12.7 10 - 16 10 - 16 12 - 20 12 - 20 14 - 25.4 16 - 25.4 LENGTH OF PRODUCTION mm 50 - 250 16 - 150 80 - 300 20 - 202 100 - 305 30 - 160 50 - 252
A: We are the biggest dealer of machines related to fastener area, and we are the agent of China biggest bolt former manufacturer, heat-treatment furnace, and so on. .
2. Q: Why should we choose you?
A: We choose the best supplier out of hundreds of similar factories, which assures that our product is of the best quality.
B: We have more than 20 years experience in this area.
C: We can provide all machines to equip an entire bolt/nut production line.
D: Fully support in buyer workmen training.
E: Fully support in after-sales service.
3. Q: What about your price?
A: The price based on your details request, like your product size, machine model, order quantity, and so on.
4. Q: How about the shipping?
A: ocean shipping, air transportation.
5. Q: Do you offer after-sale service?
A: yes, we offer full and good service for all our clients. We will always be there for you, if you have any questions.
RBF series passed CE certification, mainly produce 3die 3 blow, 4 die 4 blow, 5 die 5 blow, 6 die 6 blow multi station heading machine, boltmaker machine including thread rolling unit and tapping machine. The machine has high efficiency and consequently used to produce various fasteners, nonstandard products for automobile, motorcycle, bicycle and basically machinery work piece. Also produce nonstandard-machine in accordance with special requirement
FORGING STATION
1. Q: Are you factory or trading company?
A: We are the biggest dealer of machines related to fastener area, and we are the agent of China biggest bolt former manufacturer, heat-treatment furnace, and so on. .
2. Q: Why should we choose you?
A: We choose the best supplier out of hundreds of similar factories, which assures that our product is of the best quality.
B: We have more than 20 years experience in this area.
C: We can provide all machines to equip an entire bolt/nut production line.
D: Fully support in buyer workmen training.
E: Fully support in after-sales service.
3. Q: What about your price?
A: The price based on your details request, like your product size, machine model, order quantity, and so on.
4. Q: How about the shipping?
A: ocean shipping, air transportation.
5. Q: Do you offer after-sale service?
A: yes, we offer full and good service for all our clients. We will always be there for you, if you have any questions.
For more information ,please visit our web site: cmcmachine.en.made-in-china.com
for any questions,please feel free to contact me.
Best regards,
Vera
