Hydraulic Coils Final Forming Machine
NINGBO HI-TECH WEDE MOTOR MACHINES CO., LTD.- Automatic Grade：Semi-Automatic
- Warranty：1 Year
- Processing Part：Coils Inserted Stator After Lacing
- Transport Package：Ply-Wooden Case
- Trademark：WEDE
- Origin：China
Base Info
- Model NO.：WD-1516-JZ31
- HS Code：8479811000
- Production Capacity：100PCS,Year
Description
Basic Info.
Model NO. WD-1516-JZ31 HS Code 8479811000 Production Capacity 100PCS/YearProduct Description
Final forming machine is consisted of machine framework, hydraulic power system, control system, and forming tooling system. Powered by hydraulic system, machine drives the forming tooling system, so as to control the expansion and shrink of expansion blade and forming blade to complete the stator coil forming.
Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor, generator motor and pump motor.
Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required
Specification
| Item | hydraulic forming | servo motor forming |
| Size | 820x1100x2500mm | 900x1500x2500mm |
| Tooling included weight | about 400KG | about 450kgs |
| Power supply | 380V/50Hz 3 phase four wires, 2.2KW | 380V/50Hz 3 phases four wires, 2.2KW |
| Working pitch time | ≤13S/PC | ≤13S/PC |
| ID | Min 20mm | Min 20mm |
| OD | Max 210mm | Max 210mm |
| Core length | 12-200mm | 12-200mm |
