• Model NO.：ZYYX
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Machine Size：7000*1200*1500mm
• Certificate：ISO, CE, Soncap
• Machine Color：Optional
• Brand Name：Zhongyuan
• Machines Weight：About 5t
• Delivery Time：About 50days
• Operation Language：English or as Per Client`S Required
• Guarantee Time：First Year Free, Lifetime Services
• Shaft Diameter：72mm
• Forming Type：Cold Roll Forming
• Transport Package：40gp Container for One Machine
• Specification：CE SGS BV ISO
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：20sets,Month

ItemSpecification TypeColor steel sheet or galvanized steel sheetMaterialThickness(mm)0.5-0.7 Yield strength(mpa)235 -345Roller material45#Chrome steelForming speed(m/min)About 15 (excluding in cutting time)Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurementEncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)5.5KW   (Depend on final design)Hydraulic station power 2.2K W   (Depend on final design)Total power(kw)7.7KWUncoiler's loading capacityMax. Capacity: 3000kgsMachine`s sizeAbout 7*1.2*1.5m  (Depend on final design)Machine weightAbout 5000kgs
Components of machine:Decoiler1set   Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setPLC Controlling system1setRun out table 1set
Process flow:Decoiling the sheet  →  Leveling sheet →  Roll forming →  Measure length and cutting →  the Purline to the supporter
Controller:
Controller is the "CPU" of forming machine. We choose Mitsubishi PLC from Japan.
With touch screen mode, let your workers enjoy the easy operation;
With auto working mode, let your workers free their hands!






About us
We are professional in making roll forming machines since 2003. Company occupies 6650, in which 5650 for workshops.
1.  Capacity: 12-15 sets/month
2.  Delivery: in only 5-8 weeks for urgent order
3.  Have our own tool center. 12 sets CNC machines.
4. Zhongyuan is a "All-in-house source"
     --from raw material to the final high-precision forming machine. We have our precise tooling center.
5.  You can rely on our team!
      We have engineers with experience more than 15 years in metal forming industry.

Get Free:
"Send" below get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
