• Model NO.：XE1100HB2-70
• Max Coil Weigh：8t
• Transport Package：Standard for Export
• Specification：SGS
• Trademark：xuanen
• Origin：Zhejiang Hangzhou
• Production Capacity：50 Set,Year

Basic Info.

Model NO. XE1100HB2-70 Max Coil Weigh 8t Transport Package Standard for Export Specification SGS Trademark xuanen Origin Zhejiang Hangzhou Production Capacity 50 Set/Year

Product Description

Xuanen Low Speed Scroll Cutting Line




I.   BRIEF INSTRUCTION
This line is the special equipment for decoiling, leveling
and shearing the tinplate coil material.
 It is an important equipment to reduce the production cost
 by decreasing the waste of coil material in making iron tank and cover.
Adopting this scroll cutting line can help you to save coil material by about 3%-8%.
It consists of decoiler, leveler, scroll cutter, belt conveyor,
two material receiving platforms, and electric control cabinet.
The cutting frequency is 70 times per minute.

II.  MAIN SPECIFICATIONS OF THE LINE
2.1 Cutting thickness: 0.15~0.5mm;
2.2 Cutting width: 600~1100mm;
2.3 Cutting length: 460~1100mm;
2.4 Max coil weight: 8T
2.5 Maximum OD of coil material: φ1800mm;
2.6 Decoiling expansion range: φ450~φ520mm;
2.7 Cutting frequency: 70cuts/min; (when cutting length is 750-800mm)
2.8 Cutting linear velocity: 60m/min; (when cutting length is 750- 800mm)
2.9 Stacker loaded weight: 2T;
2.10 Height of stacker: 460mm (including bracket);
2.11 Length tolerance: ≤±0.25mm;
2.12 Diagonal tolerance: ≤±0.15mm;
2.13 Installed capacity: 40kW
2.14 Occupation Area: 18.6×5.2m.
