• Model NO.：900
• Customized：Customized
• Advantage：Easy to Maintenance
• Condition：New
• Color：Blue or Other Colors
• Feeding Width：1200mm
• Forming Stations：14
• Machine Size：7.2m*1.5m*1.5m
• Motor：7.5kw
• Pump：4kw
• Chain：1.5 Inch Single Row
• Frame：20mm
• Main Frame：400 H Steel
• Material of Rollers：Gcr15 with Hard Chrome Coated
• Transport Package：Nude
• Specification：Test Certification
• Trademark：JCX
• Origin：Hebei, China
• HS Code：84552210
• Production Capacity：520000PCS

Basic Info.

Model NO. 900 Customized Customized Advantage Easy to Maintenance Condition New Color Blue or Other Colors Feeding Width 1200mm Forming Stations 14 Machine Size 7.2m*1.5m*1.5m Motor 7.5kw Pump 4kw Chain 1.5 Inch Single Row Frame 20mm Main Frame 400 H Steel Material of Rollers Gcr15 with Hard Chrome Coated Transport Package Nude Specification Test Certification Trademark JCX Origin Hebei, China HS Code 84552210 Production Capacity 520000PCS

Product Description

1.1 Feeding width: 1200mm
1.2 Effective width: 900mm
1.3 Material thickness: 0.3-0.8mm

2. Process flow: Decoiling--feeding---forming---cutting---production

3. Manual Decoiler:
3.1 Material coil inner diameter: 450mm-700mm
3.2 Max coil width: 1200mm
3.3 Carrying capacity: 5T

4. Forming Device:
4.1 Number of forming steps: 14 steps
4.2 Shaft material: 45# steel with harden treatment, outer diameter 75mm
4.3 Roller material: 45# steel
4.4 Main motor power: 5.5kw
4.5 Forming speed: 8-10m/min
4.6 Voltage: 380V/50Hz/3 phase

5. Cutting Device:
5.1 hydraulic cutter
5.2 blade, puncher and mold material: Cr12 steel with quenched treated 60-62C
5.3 cutting system: Advanced hydraulic drive, automatic cutting after forming, no distorting or wasting, high level safety factor.

6. Controlling Device:
6.1 screen: 5.7 inch Taida screen from Taiwan
6.2 PLC: Taida DVP14ES from Taiwan
6.3 coder: Japanese Omron E6C2

7. Hydraulic:
7.1 Advanced hydraulic system from Taiwan
7.2 Power: 4kw

8. Simple output frame: Simple frame weld bu #8 U bar, 1 PCS of 3m

Suitable to process	Steel plate
Width of the plate	1000mm/1200mm/1250mm
Rollers	14rows
Dimensions	5.8*1.55*1.51m
Power	4kw+4kw
Thickness of the plate	0.3-0.7mm
Productivity	8-10m/min
Diameter of the roller	¢70mm
Weight	About 3.4T
Voltage	380V  50Hz 3pha
