• Advantage：Use Widely
• Condition：New
• Specification：3,4 Forging stations
• Trademark：SRH-134LL, SRH-164S, SRH-164LL, SRH-204L, SRH-254S
• Origin：China
• Production Capacity：100 Sets,Year

FORGING STATIONNo.4444444FORGING FORCEkgs120,000210,000210,000350,000350,000430,000430,000MAX. CUT-OFF DIA.mmφ15φ18φ18φ23φ23φ26φ30MAX. CUT-OFF LENGTHmm310220380240360270340OUTPUTpcs/min45 - 7060 - 10040 - 6050 - 8540 - 6040 - 6035 - 50MAX. P.K.O LENGTHmm30304646464046DIE KICK OUT LENGTHmm280170320220325175280MAIN MOTORkw3745557575110110CUT-OFF QUILLmmφ 55*70Lφ 60*90Lφ 64*100Lφ 75*120Lφ 75*120Lφ 80*130Lφ 99*150LPUNCH SIZEmmφ 60*229Lφ 75*185Lφ 75*185Lφ 90*215Lφ 90*215Lφ 120*270Lφ 120*270LDIE SIZEmmφ 86*305Lφ 100*190Lφ 100*345Lφ 125*240Lφ 125*345Lφ 140*250Lφ 148*300LDIE PITCHmm110120120140140160160APPROX. WEIGHTkgs38,00043,00060,00062,00075,000105,000131,000DIA. OF PRODUCTIONmm8 - 12.710 - 1610 - 1612 - 2012 - 2014 - 25.416 - 25.4LENGTH OF PRODUCTIONmm50 - 25016 - 15080 - 30020 - 202100 - 30530 - 16050 - 252

MODEL	SRH-103L	SRH-133S	SRH-133L	SRH-163S
FORGING STATION	NO.3	NO.3	NO.3	NO.3
FORGING FORCE KGS	80,000	115,000	115,000	190,000
MAX. CUT-OFF DIA.  MM	φ12	φ15	φ15	φ18
OUTPUT PCS/MIN	60TO130	70TO150	60TO90	60TO140
MAX. P.K.O LENGTH  MM	15	26	25	30
MAIN MOTOR  KW	22	30	30	45
CUT-OFF QUILL  MM	φ45*59L	φ63*69L	φ55*70L	φ60*90L
PUNCH SIZE  MM	φ53*112L	φ60*130L	φ60*179L	φ75*185L
DIE SIZE  MM	φ75*200L	φ86*135L	φ86*265L	φ110*190L
DIE PITCH  MM	90	98	110	120
APPROX.WEIGHT   KGS	19,500	19,500	31,000	40,000
DIA. OF PRODUCTION  MM	6 -10	8 -12.7	8 -12.7	10 -16
LENGTH OF PRODUCTION MM	20 -152	15 -120	50 -210	10 -152

FAQ:
1.      Q: Are you factory or trading company?
A:  We are the biggest dealer of machines related to fastener area, and we are the agent of China biggest bolt former manufacturer, heat-treatment furnace, and so on. .
2. Q: Why should we choose you?
A: We choose the best supplier out of hundreds of similar factories, which assures that our product is of the best quality.
B: We have more than 20 years experience in this area.
C: We can provide all machines to equip an entire bolt/nut production line.
D: Fully support in buyer workmen training.
E: Fully support in after-sales service.
3. Q: What about your price?
A:  The price based on your details request, like your product size, machine model, order quantity, and so on.
4. Q: How about the shipping?
A: ocean shipping, air transportation.
5. Q: Do you offer after-sale service?
A: yes, we offer full and good service for all our clients. We will always be there for you, if you have any questions.

For more information ,please visit our web site: cmcmachine.en.made-in-china.com
for any questions,please feel free to contact me.
Best regards,
Vera
