• Model NO.：PE-F500-2513
• Power Source：Electric
• Cutting Mode：Laser Cutting
• Main Axle Rotational Speed：≤30000rpm
• Milling Cutter Diameter：10mm
• Feeding Height：>300mm
• Controlling Mode：CNC
• Certification：CCC, RoHS, ISO9001, CE
• Carving Material：Stainless Steel
• Minimum Line Width：≤0.1mm
• Location Precision：≤±0.05mm
• Re-Location Precision：±0.02mm
• Transport Package：wooden case
• Specification：CE, SGS, ISO, TUV
• Trademark：Perfect Laser
• Origin：China
• HS Code：8501109190
• Production Capacity：50 sets,month

Basic Info.

Model NO. PE-F500-2513 Power Source Electric Cutting Mode Laser Cutting Main Axle Rotational Speed ≤30000rpm Milling Cutter Diameter 10mm Feeding Height >300mm Controlling Mode CNC Certification CCC, RoHS, ISO9001, CE Carving Material Stainless Steel Minimum Line Width ≤0.1mm Location Precision ≤±0.05mm Re-Location Precision ±0.02mm Transport Package wooden case Specification CE, SGS, ISO, TUV Trademark Perfect Laser Origin China HS Code 8501109190 Production Capacity 50 sets/month

Product Description

PE-F500-2513  500W 1325 1-3mm Metal Sheet CNC Fiber Optic Laser Cutter Machine
(Model: PE-F500-1325)
Contact: Emily


Product Dscription:
1. The fiber optic laser cutter adopts world famous Germany fiber laser technology and USA imported laser cutting head & dynamic focus system, and fiber optic laser cutter can cut and punch different kind of metal materials with high precision and high speed.
2. Since laser is transmitted by fiber, fiber optic laser cutter doesn't need to maintenance, and also doesn't need to adjust the laser optical path at all. The fiber optic laser cutter greatly reduces the machines' fault rate and prolongs the working life.
3. The fiber cutter has large cutting area from 1.5M to 3M, and the fiber cutter can also meet the demands of various kinds of metal processing.



Product Features:

 1) Excellent beam quality:  Smaller focus diameter and high work efficiency, high quality.

 2) High cutting speed: Cutting speed is more than 20m/min

 3) Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

 4)  High efficiency for photoelectric conversion:  Compare with CO2 laser cutting machine, fiber laser cutting machine has three times photoelectric conversion efficiency

 5) Low cost & Low maintenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;

 6) Easy operations: fiber line transmission, no adjustment of optical path;

 7) Super flexible optical effects:  Compact design, easy to flexible manufacturing requirements.

Application:
Applied materials of 300w Fiber Laser Cutting Machine
Fiber cutter is mainly used for carbon steel cutting, mild steel, stainless steel, silicon steel,aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials. It is an cnc laser cutters can be used to do high precision cutting. It also can be called fiber cutter machine,fiber optic laser cutter,laser cutter for metal,fiber cutter,carbon steel cutting,cnc laser cutters.
Applied Industry of 300w Fiber Laser Cutting Machine
This laser cutter for metal is applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.




Technical Data:

Model	PE-F 300-3015	PE-F 500-3015
Laser Power	300W	500W
Laser Type	Imported Fiber Laser	Imported Fiber Laser
Laser Technology	Germany Technology	Germany Technology
Working area	1500*3000 mm	1500*3000 mm
Max. cutting speed	12m/min (up to materials)	12m/min (up to materials)
Cooling Way	Air Cooling	Air Cooling
Laser wavelength	1070nm	1070nm
Minimum line width	≤ 0.1mm	≤ 0.1mm
Cutting depth	0.2-3mm	0.2-4 mm
Driving way	I mported servo motor	I mported servo motor
Transmission way	imported ball screw	imported ball screw



After- Sale Service for fiber laser cutting machine
1> All of our machine will be fullchecked by our quality control department before the shipment. We make sure that customers will be get good products from us. and all of our machine with a 12 months quality guarantee period.
2> We will enclose an "Instruction Book", "Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the customer.
3> We will offer plenty of online supports,  by email, video, telephone and fax.
4> Our engineer can make a door-to-door instruction training service.
