• Model NO.：100-200 kg,h
• Pre-Mixer Crushing Motor (Kw)：3.0
• Capacity(Kg/H)：100-1000
• Pre-Mixer Volume (L)：300-1000
• Cooling Band Nip Roll Length(mm)：600-1500
• Extruder Screw Diameter(mm)：46-80
• Grinding System Pin Disk Speed(Rpm)：7000-2900
• Grinding System Feeding Motor Power(Kw)：0.55-0.75
• Cooling Band Stainless Steel Belt(mm)：3000-5000
• Transport Package：Stardard Export Package
• Specification：CE, Sira, ISO9001: 2003, SGS
• Trademark：Yuanli
• Origin：Yantai, Shandong
• HS Code：84743900
• Production Capacity：50 Sets Per Month

ModelVolume
(L)Capacity
(kg/tank)Mixing motor
(kw)Rotary motor
(kw)Crushing motor
(kw)Mixing time
(min)Mixing speed
(rpm)Overall dimension
(mm)FHJ-300A300100~2009.5~110.55-5~1088~1301755*1072*2315FHJ-600G600300~40018.5~220.753.05~1063~952550*1300*2900FHJ-1000A1000500~60026~321.13.05~1045~65
 FHJ-1000G1000500~60026~321.53.05~1045~65

±2°C Double temperature PID auto-control. Accuracy ±2Speed adjust systemAdjustable speed by means of frequency inverterFeeding systemVariable by means of frequency inverterCooling systemWater cooledEquipped withScrew feedingPermanent strong-magnetic deviceOverall dimension(mm)
 2650*900*19002900*900*20003600*950*2260
Water coolingNip roll diameter(mm)Φ268Variable speedAdjustable speed by means of frequency inverterOverall dimension(mm)3050*1000*11004050*1200*13005050*1400*13006050*1600*13006050*1700*13005050*1800*1300
Main specificationModelMF-10NMF-15SMF-20/25SMF-30SMF-35SMF-40/50SMF-60SMain motor power(kw)7.51115222230/3745 2Pin disk speed(rpm)700065006000/45004500400040002900Classifier motor power(kw)1.12.233444Classifier speed(kw)0~28000~28000~28000~28000~28000~28000~2800Feeding motor power(kw)0.550.550.550.550.750.750.75Grinder cover motor power(kw)
 0.180.180.180.250.25
 Discharge motor power(kw)0.370.370.370.370.370.370.37Rotary sieve motor power(kw)1.51.51.51.51.51.51.5Blower motor power(kw)7.51115/22223030/3745Blower flow rate(m3/min)203040/70707680
 Seperating efficiency≥98%≥98%≥98%≥98%≥98%≥98%≥98%Particle size MESH120~350120~350120~350120~350120~350120~350120~350Capacity(kg/h)100~150150~200200~300/300~400400~500500~600600~800800~1000
2. Company Profile:

Yantai Yuanli Machinery Manufacturing Co., Ltd. is a highly regarded, privately owned specialty powder coating machinery and raw material companies with headquarter in Yantai, China. We have a presence in over 15 countries and are a technology driven organization with an extensive staff of highly experienced R&D and technical service personnel in Asia, Europe and the Americas.


3. Our Certificate:

CE Certificate
CE Certificate authorized by APRAGAZ Inspecting Authority from Belgium


4. Our Advantage & Service

-Technical Support Online Service Provided
According to customer's requirement, we provide layout (plant designer), excellent mechanical engineer, excellent electrician, etc.

-On-site Training Service Provided
In customer factory, we provide all kinds of training, including installation, commissioning

-Long-term Maintenance Provided
In the area of maintenance, we offer needs-oriented and standardized maintenance packages, such as the overhaul of components, gearboxes, in order to guarantee the safe and economic operation of plant and machinery.

-Spare Parts Replacement and Repair Service Provided
Providing spare parts for all kinds of powder coating processing equipment in long-term. And can provide tailored made spare parts according to customers' requirements. Ensure advanced craft, good material and high precision.

Formulation Provided (our advantage)
Some customers are worried their final products if can get best result, we have our own formulator (Engineer for powder coating formulation) who is testing and updating the formulation according to customer requirement all the time. And have very good experience for the formulation to support customer to make different effect powder coatings.

5. Our Exhibition Show:


We sincerely welcome you come to visit and negotiate with us!
