• Model NO.：YX65-400-425
• Advantage：Use Widely
• Condition：New
• Cold Roll Forming Machine：Roofing Forming Machine
• Dimension：5800mm*1600*1600
• Weight：7000kgs
• Forming Steps：13
• Height of Roofing：65mm
• Effective Width：300mm,400mm,50mm
• Material Width：470mm,575mm,680mm
• Material Thickness：0.4-1.0mm
• Motor Power：7.5kw*2
• Hydraulic Power：2.2kw
• Transport Package：Standard Package for Export
• Trademark：XHH
• Origin：Xiamen of China
• HS Code：84552290
• Production Capacity：10-15 Sets,Month

Basic Info.

Model NO. YX65-400-425 Advantage Use Widely Condition New Cold Roll Forming Machine Roofing Forming Machine Dimension 5800mm*1600*1600 Weight 7000kgs Forming Steps 13 Height of Roofing 65mm Effective Width 300mm,400mm,50mm Material Width 470mm,575mm,680mm Material Thickness 0.4-1.0mm Motor Power 7.5kw*2 Hydraulic Power 2.2kw Transport Package Standard Package for Export Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 10-15 Sets/Month

Product Description

YX65-400-425 Aluminum Roofing Roll Forming Machine, Roofing Forming Machine and Rolling Machine:

Main Accessories:
(1) Main Standing Seam Roof Panel Machine;
(2) 5 Tons Manual Decoiler;
(3) Hydraulic System;
(4) PLC Computer Controlling System with touch screen;
(5) Device for making taper standing seam roofing;
(6) Hydraulic Forming Cutter;
(7) Run out table;
(8)Manual Seamer;
(9) Tools;

1.	Size	5800*1600*1400mm
2.	Weight	7000KGS
3.	Motor Power	7.5KW*2 sets
4.	Hydraulic Power	2.2KW
5.	Voltage	380 V/60HZ/3PH
6.	Forming Steps	13
7.	Forming Speed	8-14m/min
8.	Effective Width	300mm,400mm,500mm
9.	Material Width	470mm,575mm,680mm
10.	Material of AL-Mg-Mn,Galvanized Sheet Thickness	0.4-1.0mm
11.	Material of Colored Prepainted Sheet Thickness	0.5-0.8mm
12.	Material for All Roller	high grade no.45 forged steel,plated hard chrome and polished the rollers
