Tri-Metal Rivet Contact Machine Tri-Metal Rivet Machine
HARBIN RAINBOW TECHNOLOGY CO., LTD.- Head Dia.：2-8
- Max Thinckness：3
- Transport Package：in Container
- Specification：20′CONTAINER
- Trademark：RB
- Origin：China
Base Info
- Model NO.：HFC36-3
- Production Capacity：100sets
Description
Basic Info.
Model NO. HFC36-3 Production Capacity 100setsProduct Description
Trimetal Composite Contact Cold Header can make six different metals be compounded together under cold state to produce composite contacts according to the technique requirements. Its working process includes the following steps: Sending two different kinds of metal wire into the machine firstly, transmitting them into the mould after being cut off. Then by two times upsetting process, the two kinds of metal become the composite contacts. Finally, the products retreat from the mould and enter into the finished product box.
Specification:
| Model | HFC36-3 |
| Motor Power: | 3Kw |
| Machine Power: | 3.6Kw |
| Power Supply: | 380v50hz |
| Output: | 4000-8000pcs/h |
| Transducer: | 5.5Kw |
| Dimension(LxWxH): | 1530x1020x1420mm |
| Head Dia: | 2-8mm |
| Head Thickness: | Max 3mm |
Packing Condition
