• Model NO.：AUTO
• Type：Pipe and Tube Bending Machine
• Application：Oil&Gas, Refinery Facilities, Offshore&Shipbuildin
• Type for Cutting Machine：CNC Cutting Machine
• Type for Fold-Bending Machine：CNC Fold-Bend Machine
• Certification：ISO 9001:2008, Ce
• Automation：Automatic
• Type for Pipe and Tube Bending Machine：Multifunction Rolling Pipe Bender
• Condition：New
• Transport Package：Packed in Container
• Specification：ISO9001: 2008
• Trademark：NAEC
• Origin：China
• HS Code：85153190
• Production Capacity：200 Sets,Year

Basic Info.

Model NO. AUTO Type Pipe and Tube Bending Machine Application Oil&Gas, Refinery Facilities, Offshore&Shipbuildin Type for Cutting Machine CNC Cutting Machine Type for Fold-Bending Machine CNC Fold-Bend Machine Certification ISO 9001:2008, Ce Automation Automatic Type for Pipe and Tube Bending Machine Multifunction Rolling Pipe Bender Condition New Transport Package Packed in Container Specification ISO9001: 2008 Trademark NAEC Origin China HS Code 85153190 Production Capacity 200 Sets/Year

Product Description

AUTO Two-axis/Six Axis CNC Flame / Plasma Pipe Cutting and Profiling Machine

It has features as following:
1.  Several models available (16"type, 24" type, 32" type, 48" type, 60" type);
2. Cutting precision: + 1mm;
3. PLC system control;
4. High efficient pipe cutting with automatic self-measuring, pipe end beveling; intersection line profiling for both main and branch pipe function;
5.   Multi-axis cutting machine can profile more complicated outlines with bevel;
6.   Widely used for C.S / Alloy Steel pipe fabrication.

Technical Data:

1	Product Name	Roller-bed type five-axis pipe cutting & profiling machine
2	Input Voltage	3PH AC380v/415v,50/60Hz
3	Input Power	20kw
4	Raw Pipe Length	1000~10000mm
5	Raw Pipe Doameter	50~630mm
6	The Max.Load	750kg/m
7	Totating Speed of Roller-bed	7.2rpm
8	Conveying Speed	2m/min~20m/min
9	Model	AUTO ICM630-A

AUTO Two-axis/Six Axis CNC Flame / Plasma Pipe Cutting and Profiling Machine can be used for the cutting and beveling with various pipe materials in fixed angle, different pipe end shapes, grooves and holes. It is consists of CNC rotating and lifting roller conveyor, CNC vertical cutting carriage, guide rail, electric control system, air course system, plasma system, loading/unloading mechanism, etc. By feeding the workpiece onto the CNC rotating/lifting roller conveyor, and then lowering the conveyor leaving workpiece onto the rotating roller, it is able to cut and bevel pipes automatically with selected parameters through Programmed Control System.

The combination of automatic programming and manual programming can realize the jacking cutting, with the function of cutting uprightly, cutting in any angle (manual adjustment), cutting with angle turning, multi-section elbow unfold cutting, intersection line cutting of plug-type/riding-type, etc. It is with characteristics of reasonable organization, easy operation, and high efficiency.
