• Model NO.：double bending
• Material：Metal
• Application：Metal Processing Machinery Parts, Metal forging Machinery
• Transport Package：Wooden Package by Export Standard
• Specification：L26500*W3500*H4500
• Trademark：KCM
• Origin：Chuzhou, Anhui, China
• HS Code：8455221000
• Production Capacity：50set ,Per Year

Basic Info.

Model NO. double bending Material Metal Application Metal Processing Machinery Parts, Metal forging Machinery Transport Package Wooden Package by Export Standard Specification L26500*W3500*H4500 Trademark KCM Origin Chuzhou, Anhui, China HS Code 8455221000 Production Capacity 50set /Per Year

Product Description

Features:

1. Process Flow as The Following Program:

             Automatic loading→Punching→Rolling machine→End sides double sheets bending machine→End sides vertical                     bending machine→Unloading.
          2. Adjustable in Width and Length:             The Function of Full-Automatic Length Adjustment is reacted by Servo Motor and its Mechanical Device, in addition,               Positioning Pin executes with Manual Mode to complete The Width Adjustment. The Servo Motor are made from                   DELTA, Taiwan.
          3. Other Info:              See details from attached Layout Drawing and Technical Instructions. (Signed on both sides)

              Dimension(mm): L26500*W3500*H4500;
              Standard Operation Height: 900mm from Ground Level;
              Working Stations: Designed by Requests;
              Workpiece Ratio: 30 seconds per set;
              Sheet Material & Thickness: PCM, 0.45mm~0.55mm.
              The Adjustable Range(mm): Single Side Panel(H*D)=(1300~1850)*(500~650);
              Electric Supply: AC380V, 50Hz, 45KW(in total);
              Compressed Air: 1/2"(0.5-0.65Mpa);
              Water Supply: Industrial water. (25 litres/minute)
