Semi-Automatic Charpy Impact Testing Machine/Dial Scale Display

Laizhou Laihua Testing Instrument Factory
  • After-sales Service：Technical Guidance
  • Transport Package：Wooden
  • Specification：500*1000*600
  • Trademark：Laihua
  • Origin：China

Base Info

  • Model NO.：JB-300B
  • Production Capacity：100set,Month

Description

ModelJB-300BJB-500BDisplay modeDial scale displayImpact energy300J/150J500J/250JDistance between pendulum center to impact point750mm800mmImpact velocity5.2m/s5.4m/sPendulum preparing angle150ºSpan of specimen seat40+0.2mmRound angle radius of GripsR1-1.5mmRound angle radius of striking edgeR2-2.5mm, R8±0.08mmAngle of impact knife30°Specimen size10 (7.5, 5, 2.5)mm*10mm*55mmPower supply3 phases 4 lines, 50Hz, 380VWeight550Kg750KgSemi-Automatic Charpy Impact Testing Machine/Dial Scale Display

Packaging and shipping
Packaging: Standard export package, wooden case
Delivery: 3 days upon receipt of payment, depend on order quantity

Company Information:
Laizhou LaiHua Testing Instrument Factory was founded in 2010,which specializes in the manufacture of hardness testers  and metallographic equipments for metaland nonmetal materials. Besides, we can also design special, large-scale dedicated machines according to the requirements of customers.
