• Model NO.：DF Series
• Transport Package：Woodern Case
• Specification：60DF, 80DF, 100DF, 120DF, 160DF, 180DF, 220DF.
• Trademark：HONE PAN
• Origin：Zhucheng, China
• HS Code：84484950
• Production Capacity：20000 PC Per Year

Basic Info.

Model NO. DF Series Transport Package Woodern Case Specification 60DF, 80DF, 100DF, 120DF, 160DF, 180DF, 220DF. Trademark HONE PAN Origin Zhucheng, China HS Code 84484950 Production Capacity 20000 PC Per Year

Product Description

1. DF Series Cam Indexer Features:
1) high precision.
2) good performance of high speed.
3) smooth running.
4) large transmission torque.
5) self-locking during positioning.
6) compact structure.
7) long service life.

2. Product Details:
As the increasing demand of modern industry for automation, high-speed, high precision of products, cam indexer has been widely used in many kinds of automation equipment. Cam indexer is an ideal intermittent transmission mechanism which could turn continuous running of automation equipment into stepping action.

Flange Model (DF) introduction:
The end of output is flange. It is suitable for all kinds of dial machines.

Flange Model (DF) includes: 38DF, 45DF, 60DF, 63DF, 70DF, 80DF, 100DF, 110DF, 125DF, 140DF, 150DF, 180DF, 200DF, 250DF, 350DF. .

3.Specification of 110DF:

Item	Symbol	Unit	Value
Output allowable radial load	C1	Kgf	1195
Output allowable axial load	C2	kgf	1495
Output allowable torque	Ts	Kgf-m	Refer to Torque Capacity Table
Input allowable radial load	C3	Kgf	1095
Input maximum bending moment	C4	Kgf	1955
Input maximum torque	C5	Kgf-m	336
GD2 of input shaft (note 1)	C6	Kgf-m2	0.39
Indexing accuracy		Sec.	±30
Weight		Kg	225

Note 1: GD2 of input shaft is a value in dwell range.
Note 2: Value of C1 to C5 are those obtained for safety factor=2.



4. Company, Packaging & Shipment


5. FAQ:

1) Customize prodcuts are available ?
     Yes, Customize products are available. We could design and produce products according to your     requirements or darwings. You just need to tell us your detailed requirements and our technicists will design and provide materials for your confimation. If all is ok, the production will be arranged.

2)  What's your payment terms?
    For small order, considering the value is not large, the payment terms are 100% T/T in advance.
    For large order, we could negotiate.

3) how about the packaging and shipment?
    Packaging : in box (wooden case).
    Shipment : according to customer's instruction.

4) How about the lead time ?
   For common model, the lead time is about 15 workdays;
   For customize model, the lead time is longer, about 30 workdays.

5) How about the quarantee period ?
    In generall, the quarantee period - one year for assembly unit from the date of sale .
