• Model NO.：GPD
• Condition：New
• Transport Package：Applicable for Shipment
• Specification：Gpd-40,1422x12200
• Trademark：SLJS
• Origin：Shanghai, China
• Production Capacity：100PCS,Year

Basic Info.

Model NO. GPD Condition New Transport Package Applicable for Shipment Specification Gpd-40/1422x12200 Trademark SLJS Origin Shanghai, China Production Capacity 100PCS/Year

Product Description

The machine consists of headstock, base, cutter-head, clamping device, supporting, carrier roller, hydraulic system, lubricating system and electrical control system. The machine serves to cut to length and chamfer for two ends of pipe. Two sets of cutting mechanisms including sliding table and cutter-head are arranged face to face at two ends of pipe. The pipe is lifted after coming into the middle of two cutting mechanisms; Two sets of cutting mechanisms synchronously finish the approaching, clamping and processing working of the pipe. Except the approaching of sliding table is driven by the rack and pinion pairs, other actions are driven by the hydraulic and electrical system with high automatic and efficiency.

Model Name	GPD-40/1422× 12200	GPD-40/1524× 12200
Pipe diameter (mm)	508-1422	508-1524
Pipe length (mm)	8000~12200	8000~12200
Wall thickness (mm)	8~40	8~40
Diameter of cutter head (mm)	1900	2000
Cutter quantity on cutter head (pcs)	4	4
Fixed cutter quantity on each cutter head (pcs) (cutting length ≥ 30mm)	1	1-2
Rotating range of cutter head (r/min)	15~80	15~80
Clamping type of pipe clamping device	Combined clamping by two hydraulic oil cylinders	Combined clamping by two hydraulic oil cylinders
Driving type of pipe lifting device	Combined lifting by two hydraulic oil cylinders	Combined lifting by two hydraulic oil cylinders
Total power of motor (Kw)	300	260
Working efficiency (pcs. /h)	6~12	6~10
Overall dimensions(L× W× H) (mm)	20200× 8900× 2800	20200× 8900× 2800
Weight (kg)	180000	160000
