Metal Milling Machine CNC Steel Milling Machine 5 Axis Mini High Accuracy CNC Milling Machine
Jinan Remax Machinery Technology Co., Ltd.- After-sales Service：1 Year
- Carving Material：Metal
- Controlling Mode：CNC
- Main Axle Rotational Speed：≤24000rpm
- Milling Cutter Diameter：Customized
- Feeding Height：Customized
Base Info
- Model NO.：6060
- Certification：CE
- Warranty：24 Months
- Customized：Customized
- Condition：New
- Product Name：6060 mm CNC Engraving Carving Machine
- X,Y,Z Working Area：600X600X200mm
- Frame：Cast by Iron
- Spindle Power：2.2 Kw Water Cooling Spindle
- Table Surface：T-Slot Table
- Inverter：Fuling Inverter
- X, Y,Z Structure：Hiwin Rail Linear Guide and Ball Screw
- Limit Switch：Omron
- Spindle Speed：0-24000rpm
- Drive Motors：Leadshine Stepper Motor
- Transport Package：Container
- Specification：300x400x200mm
- Trademark：REMAX
- Origin：Shandong, China
- HS Code：8465990000
- Production Capacity：25,Month
Description
Overview
Product Description
Product Parameters
| Description | Parameter of cnc milling machines |
| X,Y,Z Working Area | 600x600x200mm |
| X,Y,Z Traveling Positioning Accuracy | ±0.02mm |
| X,Y,Z Repositioning Accuracy | ±0.02mm |
| Table Surface | T-slot Table |
| Frame | cast by iron |
| rotary axis size | 150x150mm |
| X, Y,Z Structure | Hiwin Rail Linear Guide and Ball Screw |
| Max. Rapid Travel Rate | 15m/min |
| Max. Working Speed | 8m/min |
| Spindle Power | 2.2 KW water cooling spindle |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Leadshine stepper Motor and driver |
| Working Voltage | AC220/380V/50/60Hz,3PH |
| Command Language | G Code |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
| Inverter | Delta/Fuling |
| Electrical components | with |
| Operating System | Mach 3 6 axis control system |
| Computer Interface | USB |
| Flash Memory | 128M(U Disk) |
| X,Y Resolution | <0.01mm |
| Software Compatibility | powermill /Type3/UcancameV9 Software, (Option: Artcam Software) |
