Directly Powder Box Feed Coating Machine with Spray Gun
Hangzhou Feifu Import and Export Co., Ltd.- After-sales Service：12 Moths
- Warranty：1year
- Type：Powder Coating Machine
- Coating：Powder Coating
- Substrate：Iron
- Certification：CE, ISO
Base Info
- Model NO.：COLO-668-TC
- Condition：New
- Brand：Colo
- Packaging：Carton,Wood Case
- Delivery：3-5days After Depoist
- Name：Directly Powder Box Feed Coating Machine with Spra
- Power Range：220V
- Frequency：50Hz
- Operational Method：Manual
- Packing Dimension：69X56X52cm
- Packing Weight：45kg
- Transport Package：Carton
- Specification：CE ISO
- Trademark：FF
- Origin：Zhejiang Hangzhou
- HS Code：8424899990
- Production Capacity：100sets,Month
Description
The structure of equipment
1 control unit 2 Manual powder gun
3 injector 4 Mobile frame with hand rail
5 Fluidizing/suction unit 6 Vibrating table
7 Filter unit 8 Swivel arm
9 Gun holder 10 Hose holder
11 Shelf 12 Swivel wheel
13 Rubber wheel
Technical Data
Electrical data
Power range 100- 240V
Frequency 50HZ
Temperature range in use -10 ºC+50 ºC
Powder Gun
Gun weight: ......... 500G
Rated output voltage ...… 24VDC
Input voltage ......… - 200kv
Maximum output current ...… 180Ua(max)
Maximum output voltage...... 0-100KV ( adjustable)
Maximum powder injection :...… 600g/min
Polarity ......... negative (-)
Pneumatic data
Maximum input-air pressure ........ 10kg/cm
Optimum input-air pressure..... 6kg/cm
Minimum input-air pressure ... 4kg/cm
Maximum water vapor content or compressed air ….. 1.4g/N m3
Maximum oil vapor content of compressed air ..... 0.1ppm
Maximum compressed-air consumption...… 13.2 m3/h
SumMrry Summary of the advantages
1,High transfer efficiency
2,Perfect coating results
3,Well balanced ergonomic handling
4,Simply and easy maintenance
5,Robust and lightweight design
6,Wide range of accessories
7,intelligent function:
More Details Contact with us
