Electrical Wire Cutting machine \Bm400c-C
Suzhou Baoma Numerical Control Equipment Co., Ltd.- Color：Grey
- Brand：Baoma
- Casting：Ht250
- Transport Package：Exporting Standard Package
- Specification：ISO9001; ISO14001; CE
- Trademark：Baoma
Base Info
- Model NO.：BM400C-C
- Origin：China
- HS Code：8456301090
- Production Capacity：120set, Month
Description
CNC WIRE CUT EDM BM400C-CUnit BM400C-C Worktable size (L x W) mm 420 x 650 Table travel(X x Y) mm 320 x 400 Max. workpiece thickness mm 300 Max. taper angle/plate thickness degree/mm 6 Max. machining speed mm²/min 250 Precision Octagon mm ≤0.01 taper mm ≤0.04 Max. working current A 8 Roughness, three cutting μm ≤1.0 Wire diameter mm 0.15~0.2 Wire travelling speed m/min 5~11 Load of table Kg 400 Working solution working solution BM-2/BM-4 or Saponification Liquid Working reservoir capacity L 56 Power supply 3N-380V/50Hz Power consumption KVA 3 Wire guide frame Adjustable Machine dimensions(L x W x H) mm 1450 x 1000 x 1550 Package dimensions(L x W x H) mm 1800 x 1400 x 1800 Machine weight Kg 1700 Controller type BMW-5000
UNIVERSAL PARAMETERS
Max. Cutting Speed250 mm2/Min. Wire Speed 5 - 11 m/Min Max. working Current 8 A Wire Diameter Dia. 0.15-0.2mm Work Solution BM2/BM4 Water Base Working solution Water Tank 100L Rated Voltage AC~,3N, 220-415V,50/60HZ Ratde Power 3 KVA Wire Guide Frame Adjustable Controller BMW-5000
