• Model NO.：CUT160
• Model Number：Cut160I or as Your Demands
• Main Technology：IGBT Inverter Technology
• Real Max Current(a)：160
• Color：Any Color You Wanted
• Package：Plain or Colorful Carton
• Dimention of Carton(mm)：765*460*675
• Workpiece Thickness(mm)：1.0-60.0
• Base Material：Carbon Steel,Stainless Steel,Low-Alloy Steel
• Warranty Time：1 Year
• Transport Package：Standards Sea Carton or Customized
• Specification：CE
• Trademark：N,M
• Origin：Shenzhen, Guangdong China
• HS Code：8456901000
• Production Capacity：as Order

TypeLGK-160control modeIGBT inverterRated input voltageAC380VRated input current(A)40Rated input capacity(KVA)26.3Rated output current(A)160Cable cross-sectional areamains input(mm2)8power output(mm2)25ground wire(mm2)4Rated output voltage(V)144Duty cycle(%)100Rated no-load voltage(V)315Current adjustment range(A)40-160Quality cutting thickness (carbon steel)(mm)1~35Maximum cutting thickness (carbon steel)(mm)55Using plasma gasCompressed airGas pressure range(MPa)0.4-0.6Applicable air compressor capacity(m3)≥0.6Arc ignition modeHigh pressure non-contactEnclosure ratingIP21SInsulation ratingFCooling methodAirPower factor0.93Dimensions(mm)820*390*940Host weight(KG)70
