380V/160A, DC Inverter, IGBT Module Plasma Cutting Tool/Equipment Cutter Machine-Cut160
Shenzhen General Welder Technology Co., Ltd.- Customized：Non-Customized
- Layout：Vertical
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Semi-Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Model NO.：CUT160
- Model Number：Cut160I
- Main Technology：IGBT Module Inverter Technology
- Real Max Current(a)：160
- Dimention of Carton(mm)：765*460*675
- Workpiece Thickness(mm)：1.0-60.0
- Base Material：Carbon Steel, Stainless Steel, Low-Alloy Steel
- Warranty Time：1 Year
- Transport Package：Standards Sea Carton or Customized
- Specification：CE
- Trademark：N,M
- Origin：Shenzhen, Guangdong China
- HS Code：8456901000
- Production Capacity：as Order
Description
TypeLGK-160 control mode IGBT inverter Rated input voltage AC380V Rated input current(A) 40 Rated input capacity(KVA) 26.3 Rated output current(A) 160 Cable cross-sectional area mains input(mm2) 8 power output(mm2) 25 ground wire(mm2) 4 Rated output voltage(V) 144 Duty cycle(%) 100 Rated no-load voltage(V) 315 Current adjustment range(A) 40-160 Quality cutting thickness (carbon steel)(mm) 1~35 Maximum cutting thickness (carbon steel)(mm) 55 Using plasma gas Compressed air Gas pressure range(MPa) 0.4-0.6 Applicable air compressor capacity(m3) ≥0.6 Arc ignition mode High pressure non-contact Enclosure rating IP21S Insulation rating F Cooling method Air Power factor 0.93 Dimensions(mm) 820*390*940 Host weight(KG) 70
