The Forth Axis Disc Brake CNC Rotary Table Tailstock of CNC Machine Accessories
Dongguan Tonlo Machinery Technology Co., Ltd.- Certification：CE
- Customized：Non-Customized
- Material：Metal
- Disc Size：170mm
- Run Through Diameter：20mm
- Center Height：135mm
Base Info
- Model NO.：TL-T210-01
- Locking Force：16kgf,M
- Weight：22kg
- Transport Package：Hard Cartons
- Trademark：TONLO
- Origin：China
- HS Code：87089910
- Production Capacity：10000PCS,Y
Description
Basic Info.
Model NO. TL-T210-01 Locking Force 16kgf/M Weight 22kg Transport Package Hard Cartons Trademark TONLO Origin China HS Code 87089910 Production Capacity 10000PCS/YProduct Description
The rotary tailstock is ideal for applications that involve large heavy workpieces or for use with fixture plate. The rotary tailstock uses a pneumatic or hydraulic brake system to ensure the workpiece or fixture remains rigid during the machining process.Code No. | Unit | RD170R |
|---|---|---|
Table Diameter | mm | 210 |
Center Height | mm | 160 |
Front Spindle Hole | mm | 35H7 |
Spindle Hole | mm | 20 |
| T Slot Width | mm | 12H7 |
Guide Block width | mm | 14H7 |
Motor | FANUC FANUC MITSUBISHI | 4/4000i s8/3000 HF-104T |
Motor Interface | 130 | |
| Gear Ratio | 1/36/45 | |
Table Max. | R.P.M | 83 |
