CE/SGS/ISO9001 CNC Vertical Machine Center (CHV 850)
Creator Industry (Suzhou) Co., Ltd.- Transport Package：Wooden Case
- Trademark：Lead
- Origin：China
Base Info
- Model NO.：CHV850
- Production Capacity：25 Sets, Month
Description
| Model | CHV-850 | |||
| TRAVEL | LINEAR GUIDE WAY | |||
| X axis travel | mm | 710 | ||
| Y axis travel | mm | 460 | ||
| Z axis travel | mm | 580 | ||
| Distance from table surface to spindle nose | mm | 120~700 | ||
| TABLE | ||||
| table area | mm | 760x420 | ||
| Max. load of table | kgs | 450 | ||
| T-slot | mm | 5 x 14 x 63 | ||
| SPINDLE | 80000RPM Standard | |||
| Spindle taper | BT-40 | BT-40 | ||
| Spindle speed | rpm | 8000/10000 | 10000/12000/15000 | |
| Transmission type | Belt | Direct Drive | ||
| Spindle motor | kw | 3.7/5.5 | 3.5/5.5 | |
| Spindle cooling | Oil cooler | |||
| FEED RATE | ||||
| Rapid traverse(X, Y) | m/min | 30 | ||
| Rapid traverse(Z) | m/min | 24 | ||
| Cutting feed rate | mm/min | 1~15000 | ||
| 3 Axes motor output(X, Y, Z) | kw | 1.5/1.5/3.0 | ||
| A. T. C. | ||||
| Magazine type | Carousel | Arm | ||
| Tool magazine capacity | pcs | 16(20) | 24 | |
| Max. tool diameter | mm | 100/150 | 80/150 | |
| Max. tool length | mm | 250 | 250 | |
| Max. tool weight | kgs | 7 | 7 | |
| Tool selection | type | Fixed type | Random | |
| OTHER | ||||
| Power consumption | KVA | 20 | ||
| Floor space(LxWxH) | mm | 2340x2150x2350 | ||
| Machine weight | kgs | 4200 | ||
