New Customized Factory Price Factory Galvanized Steel Floor Decking Sheet Roll Forming Machinery with CE SGS Certificate

Hangzhou Zhongyuan Machinery Factory
  • After-sales Service：Provide
  • Warranty：1 Year
  • Rolling Shape：Decking
  • Product：Floor Deck Working Line
  • Roller Position：Horizontal
  • Roller Number：32

Base Info

  • Model NO.：floor decking machine
  • Layout：Continuous
  • Type：Cold Rolling Mill
  • Name：Floor Deck Roll Forming Machine
  • Cutter Material：Cr12 Mould Steel
  • Shafts：82mm Solid Steel
  • Machines Weight：About 15t
  • Installation Dimension：23m(Length) X 3m(Width) X 1.8m (Height)
  • Transport Package：1*40gp + 1*20gp
  • Specification：CE SGS BV Soncap
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：5sets,Month

Description

Overview

Our Advantages

Product Parameters




steel decking machine Parameters tableItermSpecification TypeColor steel sheet  or galvanized steel sheetMaterialThickness(mm)0. 8 -1.2 Yield strength(mpa)235 -345Roller material45#Chrome steelForming speed(m/min)About 15-20m/min Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steel Length measurementEncoderControl modeMitsubishi  PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)11*2KW   (Depend on final design)Hydraulic station power 5.5K W   (Depend on final design)Total power(kw)11KWUncoiler's loading capacityMax. Capacity: 5000kgs
(can be increased to be 10T)Machine`s sizeAbout 16*1.5*1.6m  (Depend on final design)Machine weightAbout 16000kgs
Components of machine:Decoiler1set   Feeding & guiding device1setPressing system1setMain roll forming machine1setCutting device1setHydraulic cutting system1setPLC Controlling system1setRun out table 1set
Process flow:Decoiler -- Feeding & Guiding -- Pressing--Roll Forming--Hydraulic Cutting - Product to Run Out Table

Packaging & Shipping



Hot Product



Company Profile



Our Clients




New Customized Factory Price Factory Galvanized Steel Floor Decking Sheet Roll Forming Machinery with CE SGS Certificate

FAQ



1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome your visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are Gold supplier of Made-in-China with SGS assessment (Audit report can be provided).
