• Model NO.：LGT
• Power：190kw
• Mimum Gap：8mm
• Voltage：380V,50Hz
• Dimension(L*W*H)：31*3.0*2.8m
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Single Thickness Accuracy：+-1.0um
• Length Errpr：+-0.5mm
• Thickness Error：+-5.0um
• Coathing Width: Max：650mm
• Transport Package：Standard Export Package
• Specification：ISO
• Trademark：GMK
• Origin：Foshan, Guangdong
• Production Capacity：2 Sets,Month

Basic Info.

Model NO. LGT Power 190kw Mimum Gap 8mm Voltage 380V,50Hz Dimension(L*W*H) 31*3.0*2.8m After-Sales Service Provided Engineers Available to Service Machinery Overseas Single Thickness Accuracy +-1.0um Length Errpr +-0.5mm Thickness Error +-5.0um Coathing Width: Max 650mm Transport Package Standard Export Package Specification ISO Trademark GMK Origin Foshan, Guangdong Production Capacity 2 Sets/Month

Product Description

1. Lithium battery vertical type coating machine

1) Coating method: Transferring type coating (available for continuous coating, gap coating and stripe
coating)
2)The coating head support base: overall vertical wall is high-rigidity type design.
3) Double winding and unwinding: efficient large-scale production
4)The coating drive: servo motor drive the back roll moving
5)Scraper adjustment: servo motor regulation and ultra-precision grating sensor closing loop control, scraper linear degree is adjustable.
6) Dry oven: upper and lower circulation blower, anterior is main rolldrive type, posterior floating type
oven.
7) Appearance: all stainless steel material, cladding treating.
8) The comma knife, special material for coating roll is ultra-precision machined
9) The wall adopts high quality steel, processed by CNC
10) All the bases eliminate stress.




2. Specifications

1) Pole sheet tension digital control
2) 100 product model parameter settings
3) Automatic length measuring/blade adjustment/speed ratio adjust function
4) Comma knife automatic thinning function
5) Automatic determines starting and ending point of thinning
6) Automatic tracking of stop point, reducing waste of pole sheet production and winding
7) Automatic tracking of the second surface coating dislocation




3.Technical Parameters


Type                 Item	LGT600-18/24	LGT750-18/24	LGT750-24-S
Coating width	Max:500mm	Max:650mm	Max:650mm
Maximum coating speed	15m/min	15m/min	15m/min
Machine speed	0~18m/min	0~18m/min	0~18m/min
Single thickness accuracy	±1.5µm	±1.5µm	±1.5µm
The areal density the error	≤ ±1.5%	≤ ±1.5%	≤ ±1.5%
Minimum gap	5mm Related to the characteristics of the coating speed	5mm Related to the characteristics of the coating speed	5mm Related to the characteristics of the coating speed
Positive and negative coated overlay error	±0.5mm	±0.5mm	±0.5mm
10mm thickness error within the coater head and tail	-10µm~ +5µm(single surface)	-10µm~ +5µm(single surface)	-10µm~ +5µm(single surface)
Length error	±0.5mm	±0.5mm	±0.5mm
Orderly winding error	±0.5mm	±0.5mm	±0.5mm
Retractable roll diameter	Max:φ550mm	Max:φ550mm	Max:φ550mm
Retractable roller diameter	2µm/m	2µm/m	2µm/m
Coater roller straightness	φ160mm Circular Run ≤ 1.5µm	φ160mm Circular Run ≤ 1.5µm	φ160mm Circular Run ≤  1.5µm
Air pressure	Over 0.5Mpa	Over 0.5Mpa	Over 0.5Mpa
Power	120Kw/160Kw	120Kw/160Kw	200Kw
Machine Dimensions(LxWxH)	25mx2.5mx2.7m (drying box 18m)   31mx2.5mx2.7m (drying box 24m)	25mx2.5mx2.8m(drying box 18m)            31mx3.5mx3.6m(drying box 24m)	35mx3.5mx3.6m(drying box 24m)

4. Package and Shipping

Packaging Details:	Standard export package
Delivery Detail:	60 days after your deposit

5. Our Company
 Established in 2002, Foshan Golden Milky Way Intelligent Equipment Co.,LTD(GMK)covers an area of 19,253squaremeters. Company existing staff 310 people,of which 101 people are technical personnel with high education background (accounting for 32.58% of total staff), 38 people are whole-time researcher ( accounting for
12.26%of total staff).

GMK company mainly manufacture hightech intelligent complete sets of equipment, including Silicone Sealant Continuous Automatic Production Line, HTV Continuous Automatic Production Line, Planetary dispersing power mixer, Static mixer, Automatic cartridge filling machine, Lithium battery pole sheet coating machine, Lithium battery pole sheet rolling machine and so on. GMK company has a good reputation in Fluorosilicone industry, Construction Sealant industry, Solar Power and Wind Power specialized Sealant industry. Domestic market share in silicone sealant industry reaches 25%.

GMK company is an innovation based company. It possesses 10 authorized invention patents, 31 authorized utility patents, copyright of 7 computer software, 1 national key new product and 14 new and high-tech products of Guangdong province.


6. Our Services

1)One years (12 months) quality guarantee service . from the date when machine was shipped. During the warranty period, our company will provide replaced parts free of charge because of quality issue.

2)Our technicians are available for oversea services. We have a professional aftersale service team, who are experienced in oversea technical service


6. Why Choosing Us?
1) Professional team and company strength:More than 10 years in this area and owning a state of  the are brand "GMK".

2) One stop shopping service and competitive price:Including raw material purchasing, equipment design,manufacture,test and shipment,save your time and purchasing cost.

3) Perfect after-sales service:One year warranty,offer technical support at any time.
