China C8 C18 C21 C25 C35 Russian Model Aluminum Metal Roofing Iron Sheets Shingle Making Glazed Tile Roll Forming Machine Factory Price

Hangzhou Zhongyuan Machinery Factory
  • Type：Mechanical Press
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：High Efficiency
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX Series
  • Customized：Customized
  • Advantage：Easy to Maintenance
  • Condition：New
  • Operation Language：English or as Per Client`S Required
  • Certificate：CE
  • Guarantee Time：First Year Free, Lifetime Services
  • Cutter Material：Cr12 Mould Steel Being Quenched Treatment
  • Cutting Style：Cut to Length
  • Rollers Material：No.45 Forged Steel, Plated with Hard Chrom
  • Shafts for Rollers：Grand Twice, 72mm Diameter Solid Steel
  • Quality System：ISO9001
  • Main Motor：7.5kw
  • Machine Type：C8 Metal Roof Roll Forming Machine
  • Transport Package：40gp Container for One Machine
  • Specification：CE SGS BV ISO
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：20sets,Month

Description

                                                    C8 Metal Roof Roll Forming MachineItemSpecification
Raw MaterialTypePre-painted steel coil & galvanized coilsThickness(mm)0.3-0.7Yield strength(mpa)235-550Roller material45# steel , coated with ChromeShaft for rollers Solid shaft with 72mm,processed with cylindrical grinderForming speed(m/min)About 20-25Output speed(m/min)About 12 for 6m length sheetSpeed adjusting modeMitsubishi frequency transformerRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)7.5KWTotal power(kw)9.9 KW

ComponentsDecoiler (manual decoiler and hydraulic decoiler for option)1set  Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setControlling system1setRun out table (auto. Stacker for option)1set
Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Hydraulic Cutting - Product to Run Out Table


About us:
1.  Customize roll forming machines since 2003.
2.  Capacity: 12-15 sets/month
3.  Delivery: in only 5-8 weeks for urgent order
4.  Company occupies 6650, in which 5650 for workshops
5.  Have our own tool center. 12 sets CNC machines.
6. Technician can be sent to your factory to install the machine and train your workers
7. Zhongyuan is a "All-in-house source"
   --from raw material to the final high-precision forming machine. We have our precise tooling center.
