High Speed Circular Die Thread Rolling Machine
HARBIN RAINBOW TECHNOLOGY CO., LTD.- Type：Rolling Machine
- Forging Forming Method：Mold Forging
- Power Source：Electric
- Feature：Automation
- Certification：ISO9001, CE
- Warranty：12 Months
Base Info
- Model NO.：ZPA28-20
- Customized：Customized
- Advantage：Use Widely
- Condition：New
- Green：Top Quality
- Die Type：Circular Die
- Transport Package：Wooden Box
- Specification：SGS CE ISO
- Trademark：Rainbow
- Origin：China
- HS Code：84639000
- Production Capacity：200sets,Year
Description
SP200,SP320
CIRCLE DIE THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
MAX.rolling pressure
KN
200
320
Rolling spiline range
Max.diameter
mm
70
70
Max.module
mm
0.75
1.25
Rolling die range
Max.outer diameter
mm
178
200
Aperture
mm
54
75
Max.width
mm
105
120
Max.center distance btw.main axis
mm
240
270
Main axis rotation
r.p.m.
28.35.45.56
19.24.31.40
Main axis inclination
±5°
±5°
Feed travel
mm
2×7
2×7
Center height
mm
900
900
Gross power
KW
10.2
12.2
Dimensions(L×W×H)
mm
1500×1700×1600
2000×1900×1650
Packing dimensions (L×W×H)
mm
2000×2000×1900
2250×2000×1900
Weight
Kg
3000
3500
ZPA28-20 Thread Rolling Machine
ZPA28-20 THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
MAX.rolling pressure
KN
200
Rolling spiline range
Max.diameter
Radial feed
mm
70
Axial feed
mm
45
Max.pitch
Radial feed
mm
5
Axial feed
mm
6
Rolling die range
Max.outer diameter
mm
178
Aperture
mm
54
Max.width
mm
140
Max.center distance btw.main axis
mm
240
Main axis rotation
r.p.m.
28.35.45.56
Main axis inclination
±5°
Feed travel
mm
0-12
Center height
mm
900
Gross power
KW
11
Dimensions(L×W×H)
mm
1550×1460×1600
Packing dimensions (L×W×H)
mm
1800×1750×1900
Weight
Kg
2800
Function & Feature |
1 Machine tools feed with double oil cylinders 2 intermittent rolling 3 free indexing works, 4 It is by the high-precision hydraulic workpiece clamping thimble rolled. 5 precision and efficient. 6 reasonable structure. |
C. Payment: 30% advance payment, the balance by T/T before shipment.
D. Shipment: within 3 months from the date of advance payment date.
E. Packing: Seaworthy packing.
F. Insurance: Will be covered by The Buyer.
G. Warranty: 12 months from the date of delivery for free replacement against the defective/faulty design/poor workmanship.
H. Inspection: At Seller's plant by Buyer before dispatch.
We are the biggest dealer in China. We can get the best price from Manufacturer.
We can get lower price than you purchase from manufacture directly and we can give you best after-sale service.
We have engaged in exporting more than 20 years.
80% fasteners machine in INDIA Import from us.
Such as Deepak , Empire ,Poojafore , LPS they all use our machines.
We engaged in exporting good quality products. We can give you the best price and best after-sale services.
If you have any questions, we can send engineer to your city solve problem for you.
For any questions,please feel free to contact me.
Look forward to cooperate with you.
