Coil Sheet Automatic Feeder with Straightener for Press Machine Use in Household Appliances Manufacturers
GUANGDONG RUIHUI INTELLIGENT TECHNOLOGY CO., LTD.- Type：Straightener Feeder
- Usage：Material Straightening
- Voltage：380V
- Automatic Grade：Automatic
- Principle：Large Deformation
- Certification：TUV, ISO9001, CE
Base Info
- Model NO.：MAC2-400
- Warranty：12 Months
- Customized：Customized
- Condition：New
- Stock Width(mm)：50-400
- Stock Thickness(mm)：0.3-3.2
- Line Speed(M/Min)：16-24
- Coil Weight(Kg)：3000
- Transport Package：Wooden Box
- Specification：3000*2600*2200mm
- Trademark：RUIHUI
- Origin：China, Dongguan
- HS Code：8462219000
- Production Capacity：30 Sets Per Mont
Description
Overview
MAC2-600MAC2-800 Stock Width(mm) 50-400 50-600 50-800 Stock Thickness(mm) 0.3-3.2 0.3-3.2 -3.2 Max.Coil Weight(kg) 3000 3000 5000 5000 7000 Max.Coil O.D.(mm) 1200 1200 Coil I.D.(mm) 8 508 508 Feed Length(mm) ~500* ~500* ~500* Max. Line Speed(m/min) 16-24 16-24 16-24 Work Roll Number(pieces) upper 6
lower 5 upper 6
lower 5 upper 6
lower 5 Feed Roll Number(set) 1 1 1 Main Motor(kw) AC2.9 AC4.4 AC4.4 Mandrel Expansion hydraulic hydraulic hydraulic Reel Motor(kw) 1.5 1.5 2.2 2.2 3.7 Power(V) 3 Phase 220V/380V/50HZ Operating Air(Mpa) 0.49 0.49 0.49
Straigtening performance:Stock Width (mm)0.3 400 600 800 0.4 0.6 0.8 1.0 1.2 1.4 1.6 470 470 1.8 400 400 2.0 360 360 2.3 300 300 300 2.5 230 230 230 2.8 150 150 150 3.2 110 110 110
*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provided,refer to coil weight().
Certifications
Why choose us?
1st,We have a high level of technical research and development team;
2nd,We can provide the design and planning of the whole plant to realize the turnkey project;
3rd, our philosophy: quality is the social responsibility;
4th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;
5th,We have a highly effective after-sales service team and get customer approval
