12000mm/800mm CNC Intersecting Wire Cutting Machine Plasma for Cutting Various Low Carbon Steel, Stainless Steel, Copper, Aluminum, H-Shaped Steel Channel Steel
Jinan Uscam Machinery Co., Ltd.- Customized：Customized
- Layout：Vertical
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- X Y Drive System：Rack and Pinion Drive, Hiwin Linear Rails
- Z Drive System：Ball Screw, Hiwin Linear Rails
- Drive Mode：Japan Yaskawa Servo
- Working Voltage：AC380V,50Hz
- Positioning Accuracy：0.03,300mm
- Connecting Way：USB Interface
- Plasma Power Source：Hypertherm, Huayuan
- Cutting Thickness：1-50 mm
- Plasma Table：Knief Table Surface
- Control System：Starfire Control System
- Software：Starcam
- Power Supply：63A,100A,120A,160A,200A,300A
- Key Words：Plasma Beam Cutting Machine
- Function：Cutting (Marking, Drilling)
- Materials：Metal Carbon,Mild,Stainless Steel, Aluminium
- Transport Package：Plywood Package
- Specification：Depend On plasma type
- Trademark：USCAM
- Origin：Jinan City
- HS Code：8456901000
- Production Capacity：500,Month
Description
ItemUnit Models LGK-63IGBT LGK-100IGBT LGK-120IGBT LGK-200IGBT LGK-300IGBT LGK-400IGBT Input Power V/Hz 3~ 380V± 15% 50/60 Hz Rated Input capacity KVA 9.5 17.8 22.2 38.8 70.1 93.5 Rated Input Current A 14.5 27 34 71 100 138 Rated Open Circuit Voltage V 300 300 300 315 380 380 Rated Cutting Current A 63 100 120 200 300 400 Rated Cutting Voltage V 106 120 128 160 200 200 Current Adj Range A 30~63 30~100 30~120 40~200 60~300 60~400 Max Cut Thickness(Steel) mm 25 40 45 65 80 90 Quality Cutting Thickness
(Steel, hand-held) mm 0.3~12 0.3~22 0.3~25 1~45 1~50 1~50 Quality Cutting Thickness
(Steel, machine) mm 6 12 15 25 35 40 Plasma gas - Compressed Air Air Pressure Mpa 0.3~0.5 0.45~0.6 0.45~0.6 Output Signal of Arc Voltage - 1: 1 / 1: 20 1: 50 / 1: 100 Arc Voltage Cutting Torch Cooling Mode - Air cooling Air cooling/Water cooling Rated Duty Cycle % 60/40° C 100/40° C Insulation Grade - F Protection Grade - IP21S Dimensions(L× W× H) mm 585x280x485 695× 320× 580 800× 380× 810 890× 420× 900 Power Source N. W. Kg 26 51 52 82 140 145
After-sales Service 1. 24 months-quality guarantythe machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period without human damage.
2. Free training course at our plant.
3. We will provide the consumable parts at an agency price when you need replacement.
4. 24 hours on line service each day, free technical support.
5. Our staff can be sent to your company to install or adjust if necessary.
6. User-friendly English manual and video CD for machine using and maintaining
7. My company English software can do all kinds of pattern recognition,software upgrading and updating free
(Steel, hand-held)
(Steel, machine)
After-sales Service 1. 24 months-quality guarantythe machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period without human damage.
2. Free training course at our plant.
3. We will provide the consumable parts at an agency price when you need replacement.
4. 24 hours on line service each day, free technical support.
5. Our staff can be sent to your company to install or adjust if necessary.
6. User-friendly English manual and video CD for machine using and maintaining
7. My company English software can do all kinds of pattern recognition,software upgrading and updating free
