• Model NO.：Cut200(LGK200)
• Model Number：Cut200 or as Your Demands
• Main Technology：IGBT Module Inverter Technology
• Real Max Current(a)：200
• Dimention(mm)：820*390*940
• Workpiece Thickness(mm)：1.0-75.0
• Base Material：Carbon Steel, Stainless Steel, Low-Alloy Steel
• Warranty Time：1 Year
• Transport Package：Standards Sea Carton or Customized
• Specification：CE
• Trademark：N,M
• Origin：Shenzhen, Guangdong China
• HS Code：8456901000
• Production Capacity：as Order

TypeLGK-200control modeIGBT inverterRated input voltageAC380VRated input capacity(KVA)33Rated input current(A)50Cable cross-sectional areamains input(mm2)10power output(mm2)50ground wire(mm2)4Duty cycle(%)100Rated output voltage(V)170Rated output current(A)200Rated output no-load voltage(V)330Output current adjustment range(A)40-200Quality cutting thickness(carbon steel)(mm)1-50Max cutting thickness(carbon steel)(mm)70Use plasma gasCompressed airAir pressure range(MPA)0.4-0.6Suitable air compression machine's capacity(m3)≥0.9Arc ignition modeHigh pressure non-contactEnclosure ratingIP21SInsulation ratingFCooling methodAirPower factor0.93Dimensions(mm)820*390*940Host weight(KG)75

Why choose us?

a. We have strict test and QC system to guarantee the high quality.
b. Our price is reasonable and Competitive.
c. We have 3 production lines to guarantee the delivery time.
d. R & D team provide the newest products to customers and customized products available.

Our Service :

We assure you get our best services all times.
Customized design is available.
Your business relationship with us will be confidential to any third party.

If you have any questions, please feel free to contact me!
