India Roller Shutter Door Machine Factory Price
Cangzhou Hener International Trade Co., Ltd.- After-sales Service：2
- Type：Hydraulic Machine
- Forging Forming Method：Mold Forging
- Power Source：Hydraulic Pressure
- Feature：Automation
- Certification：ISO9001, CE
Base Info
- Model NO.：1152
- Warranty：24 Months
- Customized：Customized
- Advantage：Easy to Maintenance
- Condition：New
- Transport Package：Naked and Covered by Plastic Film Into Container
- Trademark：JCX
- Origin：China
- HS Code：8455
- Production Capacity：50000
Description
Main Roll Forming System of door frame roll former machinery
Feature : Ensure stability , precision and lifetime.
Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission, roller surfaces polishing, hard plating,heat treatment and galvanized treatment . The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped.
Length of the main part: about 3500*900*1000
Weight of main part: 3 tons
Voltage : 380V 50HZ 3Phase
Roller fixer : Guide column
Frame : 400 H steel
Drive mode: chain
Material of rollers:45# steel, surface hard chromium plating.
Material of shafts: 45# steel with tempering
Diameter of shafts: φ70mm
Number of rollers : 20 rollers
Main power: 5.5kw(cycloidal planetary gear speed reducer)
Hydraulic power : 3kw
Shearing Mechanism
| Feature : Ensure stability, precision and cutting speed Function : Automatic cutting controlled by PLC |
| It adopts the hydraulic drive and automatic location to decide the dimention and cut the target products. |
| Material of blades: Gcr12 quenched Power supply : hydraulic power Frame : Pillar style with rack & pinion systme Stroke switch : non-contact photoelectric switch |
| Components:It contains one set of cutting tools, one hydraulic tank and one cutter machine.
|
