Coil Sheet Automatic Straightener Decoiler Feeder Machine and Press Feeding Line.
GUANGDONG RUIHUI INTELLIGENT TECHNOLOGY CO., LTD.- Type：Straightener Feeder
- Usage：Coiled Material Straightening
- Voltage：380V
- Automatic Grade：Automatic
- Principle：Large Deformation
- Certification：TUV, ISO9001, CE
Base Info
- Model NO.：MAC3-800
- Warranty：12 Months
- Customized：Customized
- Condition：New
- Stock Width(mm)：50-800
- Stock Thickness(mm)：0.3-4.5
- Line Speed(M/Min)：16-24
- Coil Weight(Kg)：5000-7000
- Name：Straightener Decoiler Feeder
- Colour：Customized
- Transport Package：Wooden Box
- Specification：5200*3700*2500mm
- Trademark：RUIHUI
- Origin：China, Dongguan
- HS Code：8462219000
- Production Capacity：30 Sets Per Month
Description
MAC3-800MAC3-1000 Material Width(mm) 50-400 50-600 70-800 70-1000 material Thickness(mm) 0.3-4.5 0.3-4.5 0.3-4.5 0.3-4.5 Max.Coil Weight(kg) 5000 5000 5000 7000 7000 Max.Coil O.D.(mm) Φ1400 Φ1400 Φ1400 Φ1400 Coil I.D.(mm) Φ508 Φ508 Φ508 Φ508 Feed Length(mm) ~500* ~500* ~500* ~500* Max.Line Speed(m/min) 16-24 16-24 16-24 16-24 Work Roll Number(piece) up 4 / down 3 up 4 / down 3 up 4 / down 3 up 4 / down 3 Feed Roll number(set) 1 1 1 1 Main Motor AC4.4 AC4.4 AC5.5 AC7.5 Mandrel Expansion hydraulic hydraulic hydraulic hydraulic Reel Motor(kw) 2.2 2.2 2.2 3.7 3.7 Power(v) 3 Phase 220V/380V/50HZ Operating Air(Mpa) 0.49 0.49 0.49 0.49
Stock Thickness
(mm)0.3~0.8 400 600 800 1000 1.0 750 1.2 700 600 1.6 590 480 430 1.8 500 420 380 2.0 430 370 330 2.3 360 320 290 2.8 370 290 250 230 3.2 300 250 220 200 4.5 160 160 150 110
Customer case
Manufacturing industry; the United States Lear Co, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.
And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.
hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.
RUIHUI founded in 2000, the technology of automation periphery is from Japan.RUIHUI has been learning Japan and Germany technology, and useing high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and reihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industy,and investment less.
RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.
Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.
Why choose us?
1st,We have a high level of technical research and development team;
2nd,We can provide the design and planning of the whole plant to realize the turnkey project;
3rd, our philosophy: quality is the social responsibility;
4th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;
5th,We have a highly effective after-sales service team and get customer approval
Q1:What kinds of machines do you have?
Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener Feeder,Transfer systems,Press Feeding Line., etc
Q2:Is your equipment standard or customized?
Both, we can OEM & ODM with customers.
Q3:What are your equipments certification?
All our items are coming with CE certifications.
Q4:How did your company's quality system work?
"QUALITY IS OUR CULTURE" Our quality is not the best in the world, and the price is not the cheapest. But we can provide you excellent products to defeat your competitors.
Q5:How long is the warranty period of the machine?
We offer free service with a warranty period of one year, If it is operate in reasonable, the machine can be used more than 10 years.
Q7: Is it possible to be a foreign agent and distributor?
If you are confidence and excellent service for after-sales, then welcome to be our agents or distributors all over the world.
Q9:What's your payment?
T/T,D/P,L/C,Western Union., etc
Q10:What's the delivery?
"TIME IS GOLD" for you and for us, so we have professional team work and production line can make nice quality in short time.
