• Model NO.：PE-CUT-B1 B2
• Type for Cutting Machine：Flame Cutting Machine
• Cutting Thickness：0.5-5mm
• Cutting Speed：0-6000mm,Min
• Plasma Current：60A
• Connecting Way：USB
• Rail Guide：Precision Work Round
• Transmit Way：Taiwan Imported Ball Screw
• Control Method：Use Extra PC to Control
• Cooling Method：with Water Pump and Tank Provide Circulating Water
• Transport Package：Sea-Worthy Packing or Air-Worthy Packing
• Specification：ISO9001 & CE&FDA
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456100090
• Production Capacity：100 Units,Month

Basic Info.

Model NO. PE-CUT-B1 B2 Type for Cutting Machine Flame Cutting Machine Cutting Thickness 0.5-5mm Cutting Speed 0-6000mm/Min Plasma Current 60A Connecting Way USB Rail Guide Precision Work Round Transmit Way Taiwan Imported Ball Screw Control Method Use Extra PC to Control Cooling Method with Water Pump and Tank Provide Circulating Water Transport Package Sea-Worthy Packing or Air-Worthy Packing Specification ISO9001 & CE&FDA Trademark Perfect Laser Origin China HS Code 8456100090 Production Capacity 100 Units/Month

Product Description

Cantilever Type Plasma Cutting Machine For Stainless Steel Metal SignsCantilever CNC Cutting Machine Introduction
Cantilever CNC cutting machine is a thermal cutting equipment, combined with computer control, precision mechanical transmission, oxygen and gas (propane or acetylene) cutting these three kinds of technology, with high efficiency, high precision and high reliability.
The cutting line width is 1650 mm, longitudinal cutting length is 3500 mm, the longitudinal trajectory can be set up, also can adjust the height, small volume, high mobility and flexibility, you can install multiple cutting and scribing tools, widely used in the construction machinery, sheet metal processing, agricultural machinery and other heavy industries.

Cantilever CNC Cutting Machine Technical Data

Rail distance(mm)	2200(Customized)
Rail length(mm)	4500(Customized)
Effective cutting width(mm)	1650
Effective cutting length(mm)	3500
Speed range(mm/min)	0-5000
Transverse longitudinal drive system	Stepper motor
Number of torch systems(groups)	Single flame or plasma(can be added)
Flame cutting thickness	5-180
Plasma cutting thickness	Determined by the user selected plasma power
Flame cutting gas	Oxygen+Acetylene/Propane/Natural gas/Coal gas
Control system(Permanent free upgrade)	Beijing START 2012AH
Plasma source	Domestic or imported (optional)


Cantilever CNC Cutting Machine Application
Perfect Laser provide the most efficient and most suitable cantilever CNC cutting machine for you, it widely used in a variety of carbon material cutting, low carbon steel cutting, non-ferrous metal precision sheet metal cutting.
Cantilever CNC Cutting Machine Product Features
1.Chinese or English interface control system: the operation is simple and convenient, can be cut into CAD graphics operation, automatic sorting, slotting compensation, simple nesting, without programming, simple and practical, quick to get start.
2.High precision movement: the walking part using gearless rack and pinion drive, the motor drive using advanced technology in Germany, vertical rails imported from Taiwan linear guide, to ensure high precision machine, stable operation;
3.Machine durable: use of special aluminum alloy section of the machine beam, high rigid, light weight, easy to move, long-term use without deformation. Can be placed directly on the steel plate to operate.
4.Optional Cutting mode: single flame cutting, single plasma cutting or flame plasma dual-use cutting.
5.Perfect after-sales service: after-sales team with more than 20 people, 24 hours for you to solve the various problems of the machine, the standard after-sales process, free video of operation and maintenance, let you to use it without any worry.

Company Information
We, Perfect Laser, As a 21 years history industrial equipment manufacture in laser field, 10 year Golden Supplier in Alibaba, with CE/ISO/FDA, we aims to make high quality products, and also our products have been exported to more than 180 different countries and areas.


FAQ:
Please let us know following informations:
1.What kind of materials you want to cut ?
2.What is the mostly used thickness and what is the maximum thickness?
3. What is the MAX. dimension of your materials ?
4. After cut, what will be the metal used for? (application)
5. Are you an end user or reseller?
According to your above information,we'll recommend the most suitable machine to you.
