Hypertherm Maxpro200 Plasma Cutting Machine
Shanghai Tayor Heavy Industry (Group) Co., Ltd.- Customized：Customized
- Layout：Horizontal
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Model NO.：CNCSG4000 MAXPRO200
- Transport Package：Wooden Case
- Specification：4X12M
- Trademark：TAYOR
- Origin：China
- HS Code：8456901000
- Production Capacity：500 Sets , Year
Description
1Track Width (mm) 4000 Rail length (mm) 12000 Effective Cutting Area(mm) 3000x10000 Drive Y axis Panasonic AC servo motor *2set X axis Panasonic AC servo motor *1set Max traveling speed(mm/min) 12000 2 Flame Cutting Torch Number 2Set* TAYOR Flame Cutting Thickness(mm) 6-120 Flame Torch Height Sensor Capacitance Auto torch Height sensor* 2set Flame Cutting Speed(mm/min) 50-800 3 Plasma Cutting Torch Number 1 Set * Hypertherm straight torch Plasma Torch Height Sensor Plasma Arc Auto height Sensor THC Anti-Collision Torch Holder 1set* TAYOR Plasma Cutting Speed(mm/min) 50-4500 4 Plasma source Model Hypertherm MAXPRO200 Plasma Cutting Thickness(mm):
Virtually dross-free cutting capacity-mild steel 25mm
Production pierce capacity -mild steel 32mm
Max cutting capacity (edge start)-mild steel 48mm Country of origin Made in USA Max current output 200A Power 30KW Duty cycle 100% 5 Hypertherm Hypertherm Micro EDGE pro 6 Nest Software Australia FASTCAM professional 7 PLC Taiwan Delta* 1set Electric Components Schneider and DELIXI Cables CE approached cable Solenoid valve ITALY CEME Gas Hose ITALY LOBSTER 8 Water Surface Cutting Table Made by user as per TAYOR's drawing
Working Conditions
Virtually dross-free cutting capacity-mild steel 25mm
Production pierce capacity -mild steel 32mm
Max cutting capacity (edge start)-mild steel 48mm
| Positioning Accuracy | ±0.5mm/10000mm |
| Repeatability | ≤±0.1mm |
| Speed setting error | ≤±5% |
| THC accuracy | ≤±0.5mm |
| Length of a side Error(mm) | ±0.5mm |
| Base Point Return Error | ±0.4mm |
| Intersection point Error | ±0.5mm |
| Lineation forward-reverse Error | ±0.2mm |
Working Conditions
| Power Supply Temperature Humidity Surroundings | Machine : 220v±10%;50Hz~60Hz(Customized) Plasma System: 3×380v±10%;50Hz~60Hz(Customized) -10-50 <90% /No Condensation Ventilate, No big shake |
| Oxy-fuel cutting gas type/Quality | Oxygen:0.5-0.8MPa Purity: 99.5%; Flow:1.0M 3 /Min Fuel Gas :Propane or Acetylene Pressure:0.05-0.1MPa |
| Plasma Cutting Gas type/Quality | Basically gas: Dry and oil free compressed air Pressure: 8.3kg/cm2 Flow:0.9 M3/Min The rest shield and plasma gas type and quality please refer to Plasma source Manuel |
