• Model NO.：CY05Z
• Warranty：12 Months
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Screw Dia.：3-5mm
• Screw Length：50,75
• Transport Package：Seaworthy Package
• Specification：depends on different model
• Trademark：Rainbow
• Origin：China

Basic Info.

Model NO. CY05Z Warranty 12 Months Customized Customized Advantage Use Widely Condition New Screw Dia. 3-5mm Screw Length 50/75 Transport Package Seaworthy Package Specification depends on different model Trademark Rainbow Origin China

Product Description

Machine Description

 The thread rolling machine adopts two thread profile thread rolling plate staggered 1/2 screw distance design, One plate is fixed, movable plate is on the fixed plate do straight line motion back and forth, when the work piece feed between two plates, movable plate move forward twist work piece, make its surface plastic deformation into thread. To roll thread on blank shank of bolt after being cold-headed.


Model   CY05Z	Specification
Diameter (mm)	3-5
Screw length(mm)	50/75
Thread length(mm)	50
Moving dies stationary length	76/89/25
Main motor (HP)	3
Max .output (pcs/min)	75-95
Approx. weight (KG)	1000
Machine size (mm)	1600x1300x1650

Company Profile

Our company comes from China National Machinery Import and Export Corp. Harbin branch. By many years market development and experience accumulation,now we have became the biggest Chinese fastener equipment dealer and turnkey consultants of fasteners manufacturing project for abroad customers.

  We are supplying high quality and reliable machines for the entire fastener industry with our professional and timely after sale service,our main products include wire drawing machine,Bolt Maker, Nut Maker, Part Former, Heading Machine, Thread Rolling Machine and Mesh Belt Furnace.

  With our business reputation and professionalism, our company has experienced a significant growth in business during the recent years and we invested in some fastener equipment manufacturers and built our own bolt maker,mesh belt furnace and zinc plating line factories.We do these factories' foreign market developing and have received highly praises from a lot of customers.

  We have established reputation in countries such as India, US, Europe and Southeast Asia where we have core customer bases. Meanwhile, we are well respected by the domestic factories and the customers in the mechanical and electrical business.
