Aluminum Melting 100kg Induction Furnace
Foshan Hengyang Furnace Manufacturing Co., Ltd.- After-sales Service：Online Guiding
- Warranty：1 Year
- Control Type：PLC
- Customized：Customized
- Condition：New
- Automatic Grade：Automatic
Base Info
- Model NO.：GW-0.1T
- Certification：CE, ISO9001
- Type：Melting Furnace
- Application：Melting Aluminium
- Melting Rate：100kg,Hour
- Rated Input Voltage：380V
- Rated Input Current：160A
- Rated Input Power：100kw
- Working Temperature：0-700 Degrees
- Highest Temperature：1800 Degrees
- Cooling Way：Water Cooling
- Transport Package：Wood Packing
- Trademark：HengYang
- Origin：China
- HS Code：851420009
- Production Capacity：100sets,Per Months
Description
Cast copper melting(1350ºC)(t/h) (Kw) KHZ Melting Power consumption Melting Power consumption Rate(t/h) (kw.h/t) Rate(t/h) (kw.h/t) 0.1 100 2.5 0.1 800 0.1 490 0.15 160 2.5 0.15 750 0.15 480 0.35 250 2.5 0.35 700 0.35 460 0.5 350 1 0.5 650 0.5 450 0.75 500 1 0.75 630 0.75 440 1 750 1 1 600 1 430 1.5 1000 1 1.5 580 1.5 430 2 1500 1 2 560 2 430 3 2000 1 3 530 3 430 5 2500 1 5 520 5 430 8 5000 0.5 8 520 8 430 10 5000 0.5 10 520 10 430 15 8000 0.5 15 520 15 430 20 10000 0.5 20 520 20 430 30 15000 0.5 30 520 30 430
Safety Protection:
• Main circuit short circuit protection
• Main circuit phase loss protection
• Main circuit phase fault protection
• SCR over-current protection
• SCR overvoltage protection
• Cooling water temperature protection
• Low water pressure protection
• Furnace leakage protection
• Intermediate frequency power failure protection
• Intermediate frequency electric furnace fault protection rate and increase the life obviously
Why Choose us?
1,Low power consumption
Large current system made of pure copper as conductive medium, the whole circuit with less resistance. Electrode arm shaped as copper-clad box type, resistance and heat can be reduced efficiently. Reasonable arrange of all conductive systems to minimize the resistance of every circuit.
2,Safety & Stability
Full set of hydraulic driving system equipped with accumulator to ensure stability of facilities in the operation process. Whist, equipments can go on the motion when there any emergency accidents happen.
3,High Power Factor
Our power factory could reach over 98%, which could greatly reduce the capacitor box quantities. However we still equip enough capacitor box quantities, which mean your furnace is much much more efficient.
4.High flexibility & Maximum simplicity of operation
HMI used in electrical automation control, interface simulates the real form of furnace, which make the operation more convenient. Mixing feedstock, charging feedstock, melting, tapping all the commands can be implemented by computer.
5.More Durable
We get 6 thyristors on the left, 8 on the right, so even if one thyristor is damaged, our furnace still could be continued use. But many other factories only get only 4 on the right,the whole equipment cannot be used anymore when one thyristor is damaged.
After-sales service:
a. Cooperate with guidance to check the buyer installation work;
b. Internal and electrical wiring connections between equipment;
c. Site commissioning;, according to the actual equipment adjust to the best state;
d. Direct buyer operating personnel to the correct use of operating equipment;
e. Guidance on site security considerations;
f. To guide the buyer maintenance personnel troubleshooting methods;
g. Provide equipment specification;
