10 Tons Automatic Hydraulic Decoiler Uncoiler Feeding Machine
Xiamen Xinhonghua Machinery Co., Ltd.- Type：Uncoiler
- Forging Forming Method：Tire Mold Forging
- Power Source：Hydraulic Pressure
- Feature：Automation
- Certification：SGS
- Warranty：12 Months
Base Info
- Model NO.：10T
- Customized：Customized
- Advantage：Use Widely
- Condition：New
- Size：5000*1300*1600mm
- Weight：2000kg
- Hydraulic Power：1.5kw
- Motor Power：4kw
- Max.Loading：10tons
- Voltage：220V60Hz,3pH
- Max.Width for Sheet：1250mm
- Transport Package：Standard Package for Export
- Specification：SGS
- Trademark：XHH
- Origin：Xiamen
- HS Code：8455229090
- Production Capacity：20sets,Month
Description
Basic Info.
Model NO. 10T Customized Customized Advantage Use Widely Condition New Size 5000*1300*1600mm Weight 2000kg Hydraulic Power 1.5kw Motor Power 4kw Max.Loading 10tons Voltage 220V60Hz/3pH Max.Width for Sheet 1250mm Transport Package Standard Package for Export Specification SGS Trademark XHH Origin Xiamen HS Code 8455229090 Production Capacity 20sets/MonthProduct Description
10Tons Hydraulic Uncoiler, Uncoiler Machines and Automatic Hydraulic Decoiler for roll forming machine:
Main Technic Parameter:
1. Size: 5000mm*1300mm*1600mm
2. Weight: 2000KGS
3. Hydraulic Power: 1.5KW
4. Motor Power: 4KW
5. Max. Loading: 10Tons
6. Voltage: 220V/60HZ/3PH
7. Max. Width for Sheet: 1250mm
| 1. | Dimension | 5000mm*1300mm*1600mm |
| 2. | Weight | 2000KGS |
| 3. | Hydraulic Power | 1.5KW |
| 4. | Motor Power | 4KW |
| 5. | Voltage | 220V/60HZ/3PH |
| 6. | Max.Loading | 10T |
| 7. | Max. Width for Sheet | 1250mm |
