Stainless Steel Flexible Hose Copper Wire Braiding Machine
Comflex Industrial Co., Ltd.- Braiding Diameter (mm)：10-31mm
- Carrier Rotation Speed (R/Min)：14.25r,Min
- Braiding Angle：54, 44"
- Braiding Pitch：22-69mm
- Pulling Speed M/H：21-66
- Model：Gbg24
Base Info
- Model NO.：128 carrier
- No Carrier：24
- Motor Power：3kw
- Transport Package：Standard Seaworthy Packing
- Specification：ISO9001
- Trademark：HLT
- Origin：Chian Jiangsu Wuxi
- HS Code：84485900
- Production Capacity：50000PC,Years
Description
Basic Info.
Model NO. 128 carrier No Carrier 24 Motor Power 3kw Transport Package Standard Seaworthy Packing Specification ISO9001 Trademark HLT Origin Chian Jiangsu Wuxi HS Code 84485900 Production Capacity 50000PC/YearsProduct Description
Stainless steel flexible hose copper wire braiding machineMachine description
Wire braiding machine
The wire braiding machines we can make as follows:
Wire diameter:0.3mm to 0.8mm
No.of spindles:16 to 112 spindle braiding machine
ID of the braids:4mm to 600mm
Material of wires:stainless steel,galvanized carbon steel, copper wire
Technical data
Single decker steel wire braiding technical data
| Description | Braiding diameter(mm) | Carrier Rotation Speed (r/min) | Carrier Rotation Speed (r/min) | Braiding Pitch (mm) | Pulling Speed M/H | No.carrier | Motor Power KW |
| GBG16-carrier wire braiding machine | 4-10 | 24.8 | 54°44" | 9-22 | 13-33 | 16 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG20-carrier wire braiding machine | 6-16 | 19.8 | 54°44" | 13-29 | 15-34.5 | 20 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG24-carrier wire braiding machine | 10--31 | 14.25 | 54°44" | 22-69 | 21-66 | 24 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG36-carrier wire braiding machine | 15--45 | 10 | 54°44" | 33-100 | 22-66 | 36 | Y100L2-4 3.0KW Y100L2-4 3.0KW |
| GBG48-carrier wire braiding machine | 30--75 | 7.25 | 54°44" | 66-166 | 29-72 | 48 | Y132M2-6 5.5KW Y112M-4 4.0KW |
| GBG64-carrier wire braiding machine | 51-110 | 4.56 | 54°44" | 67-240 | 18.6-102 | 64 | Y160M-6 7.5KW Y112M-4 4.0KW |
| GBG72-carrier wire braiding machine | 80-150 | 4.25 | 54°44" | 170-330 | 44-83 | 72 | Y160M-6 7.5KW Y112M-4 4.0KW |
| GBG96-carrier wire braiding machine | 150-300 | 2.75 | 54°44" | 240-750 | 50-120 | 96 | Y180L-6 15KW Y160M-6 7.5KW |
| GBG112-carrier wire braiding machine | 115-400 | 2.778 | 54°44" | 310-800 | 42-130 | 112 | Y132M1-6 4.0KW Y180L-6 15KW |
| GBG128-carrier wire braiding machine | 200-400 | 2.088 | 54°44" | 500-1300 | 72-300 | 128 | Y132S-4 5.5KW Y180L-6 15KW |
Double decker steel wire braiding technical data
| Description | Braiding Diameter (mm) | Carrier Rotation Speed (r/min) | Braiding angle | Braiding Pitch (mm) | Pulling Speed M/H | Carrier NO. | Motor Power KW |
| GBG-2S16 | 4-10 | 24.8 | 54°44" | 9-22 | 13-33 | 32 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG-2S20 | 6-16 | 19.8 | 54°44" | 13-29 | 15-34.5 | 40 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG-2S24 | 10--31 | 14.25 | 54°44" | 22-69 | 21-66 | 48 | Y100L1-4 2.2KW Y100L2-4 3.0KW |
| GBG-2S36 | 15--45 | 10 | 54°44" | 33-100 | 22-66 | 72 | Y100L2-4 3.0KW Y100L2-4 3.0KW |
FAQ for Steel Wire Braiding Machine
1. Why choose us as your supplier
We are most professional in steel wire braiding machine with more than 30
years of experience
2. What wires can you machine braid?
A. Stainless steel wire
B. Copper lad steel wire
C. Copper wire
3. What application of your braiding machine?
Popular for both rubber hose and metal hose manufacturing
We need to know the following information to quote you correct machineries:
1.What outer diameter of the hose you want to braid?
2. Structure of the braid?
How many carriers/bobbins you need for braiding your hose? For instance, 24, 36,64,72,96,128 carrier, etc..
