• Model NO.：XINTU
• Condition：New
• Advantage of PVC Booth：Non-Stick Powder, Fast Color Changes
• Transport Package：Sea Worthy Package
• Specification：customized
• Trademark：XINTU
• Origin：Jiangsu, China
• HS Code：84243000
• Production Capacity：100 Sets, Year

3.  WORKING PRINCIPLE of spray booth

For tradtional stainless, carbon steel , or metallic spray booth, in the processing of powder coating, the overspraying powder particles are easily stick onto the surface of the sidewall of spray booth caused the powder particles are with the electrostatic charges when the particles go out from the powder spray gun, Just because of this problem, it will be hard to clean the spray booth and require longer time to clean the spray booth when you want to change the colors, the slowly color-changing can't fastly take good use of the recycling powder and also add the production cost;

Regarding to the anti-static plastic spray booth ( PVC) ,because the insulation property of this engineering plastic, the electrostatic charges sticked powder particles are not so easliy to stick onto the side wall of spray booth, so it greatly brings the convenience to clean the powder;



SPECIFICATIONS

Outside size (L*W*H)

6000mm x1400mm x2400mm

AIR CONSUMPTION

15455 m³/H

BLOWER (CHINE) x 1 PC

MOTOR 380V/50HZ/3Ø  (15KW)

MATERIAL

PVC,easy to clean

CONTROL CABINET

PLC control , Dust proof ,Control the blower, pulse blowback system and lights ,easy to operate

Powder recovery system

 Mono cyclone+secondary pulse filter recovery system

Circulation system

 Refer to the powder recovery system

Blower holder system

 Made by 80*80 square tubes

 Independent from the booth to prevent the resonance and reduce the noise

Lighting system

  lights 4 pcs x 40W
