• Model NO.：PE-W500D 300D 400D
• Specification：ISO, CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：8462219000
• Production Capacity：2000 Sets

No.

Project

Tender specifications

Model

PE-W500D 300D 400D

1

Input voltage

Three-phase four-wire system, 380V ± 5%

2

Maximum output power

12KW

3

Full mirror

Reflectivity≥99.7%

4

Power supply feedback type

Current feedback

5

Condenser chamber

Gold-plated single-chamber design, dual-lamp

single rod

6

Laser wavelength

1.064μm

7

Beam divergence angle

≤8mrad/m

8

Peak output power

500W

9

Laser head adjustment

360 degrees

10

Pulse frequency

1~150Hz

11

Pulse Width

0.1~20ms

12

Current regulation

50-500A

13

Beam expander

3 times

14

Focus spot diameter

0.2-2mm

15

X-axis and Y-axis travel

X*Y=300mm*300mm

16

Table size

X*Y=400mm*400mm

17

Moving speed range

0-50mm/s

18

Reset accuracy

0.03mm

19

positioning accuracy

≤0.025mm

19

Z axis

Electric lift height 200mm

Manual lift 100mm

20

Rotating fixture

Diameter Ф100mm rotating fixture, angle 0-90º manually adjustable, can be locked in any position between them, using stepper motor drive, step equivalent of 0.01 degrees, positioning accuracy of 0.1 degrees, repeat positioning accuracy of 0.05 degrees.

21

Displaying method

Coaxial CCD LCD screen observation

22

Targeting method

Positioning method red + positioning rod

23

way of light

Automatic + manual switchable

24

Cooling system

Double cycle system, heat exchange titanium tube, over temperature alarm, flow protection, water level protection.

25

Control System

Industrial computer CNC 2000 control software
